1.Plant data:
NO. |
Name |
Parameter |
1 |
The raw materials: |
waste tyres,/plastic, oil sludge |
2 |
Daily capacity: |
10 ton/day |
3 |
The size of reactor |
2800*6000mm 16mm thickness |
4 |
Reactor material |
Q345R |
5 |
Average oil productivity: |
30%-80%, |
6 |
Average carbon productivity: |
20%-35% |
7 |
Plastic oil rate |
30%-80% |
8 |
pyrolysis time |
6-8 hours |
9 |
Discharge time |
1.5 hour |
10 |
Feeding time |
3 hourS |
11 |
Cooling time |
3 hours |
12. |
Working pressure |
Normal /slightly negative |
13 |
Power |
18 kw |
14 |
Fuel |
Coal. Wood, gas etc |
15 |
Working area |
1000 square meters |
16 |
Total weight |
35 000kgs |
17 |
Reactor rotate speed |
0.25-0.4/min |
18 |
Noise |
No less than 85DB |
19. |
Certificate |
Ce,.iso, |
20. |
Carbon slag out |
Automatic |
2.Oil rate
PE |
50%-75% |
PP |
50%-75% |
PS |
50%-75% |
ABS |
40% |
Leftovers of paper |
Wet 15-20%, dry 60% |
House garbage |
35-50% |
Plastic cable |
80% |
Plastic bag |
50% |
Submarine cable |
75% |
Rubber cable |
35% |
Sole |
30% |
Big tires |
45-50% |
Small tires |
35-40% |
PVC |
Not suitable |
PET |
Not suitable |
Big tyre |
40-45% |
Small tyre |
30-35% |
3. oil we get from waste
4.You may interest:
Type |
24hour capacity |
Batch type pyrolysis plant |
5ton,8ton,10ton 12ton,15ton |
Semi-continuous pyrolysis plant |
10ton,15ton,20ton |
Fully continous plant |
20ton ,30ton,40-60ton |
Tunnel reactor pyrolsyis plant |
15Ton 20Ton |
Lengthen Reacor pyrolysis plant |
15Ton ,20ton |
Other special customerized plant |
As customer requirement |
Continuous oil distillation plant |
5ton,10ton,15ton.30ton |
5.how can we make 100% pollution free?
a> waste-gas : during the process of pyrolysis , there will cause 5% waste-gas, but the waste-gas can be burnt again in the reactor as fuel materials to keep the temperature in the reactor, have you noticed the green hole in the reactor, the waste-gas enter into the hole and is burnt again. So there is no waste-gas at all.
b> Waste-water: there is a water-recycling system in the set of plant, all the process, the water can be used circulatory. So there is no waste-water in the process of pyrolysis
c> Bad smell: there will be some chemical substances feed into the catalysis tower and burnt together with the tires. It can get rid of bad smell and improve the quality of oil.
d> Emission controller: there is emission controller in the set of plant, it won’t cause dirty dust in the process of pyrolysis
