High Temperature Cast Iron Filter Press for Waste Oil
- Qingdao shanghai tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Stable Performance Cast Iron Hydraulic Filter Press Machine With Long Use Life
-
Hot Sale Cast Iron Filter Press Supplier, Lubricant Oil Usage Plate Frame Filter Press
-
Food Grade Filter Press Portable, Hot Sale Wine Filtering Press
-
Ceramic Mud Dewatering Machine Filter Press
-
New Condition Cast Iron Cottonseed Oil Filter Press
-
Cooking Oil Filter Machine, Plate Frame Filter With Cast Iron Plate and Frame
Product Details
| Condition | New | Automatic Grade | Automatic | |
| Production Capacity | 1-40㎡ | Place of Origin | Henan, China | |
| Brand Name | TOPER | Model Number | BQ1/320-25 | |
| Voltage | 380V | Weight | 380kg | |
| Certification | CE | Warranty | all service life | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High temperature cast iron filter press for waste oil
Our Zhengzhou Toper company produces various models of recessed filter press and plate-frame mechanical filter press, hydraulic filter press, membrane filter press and full-automatic filter press and filter press spare parts. With high quality and best sale-service, having received a good reputation.
Features of oil filter press:
1. Widely be used for dewatering high temperature various oil (engine oil, vegetable oil etc.)
2. Cast iron of plate and frame of filter press for high temperature oil filtration
3. Plate and frame of filter press, the heart of filter press
4. Material of plate and frame: cast iron
5. Max temperature: up to 300 degree celsius
6. Resistance to high temperature and high pressure.
7. Long use life.
8. External size of filter plate: 1000*1000mm
9. Best choice in high temperature oil industry
Parameters of oil filter press:
Specification | Filter area (m2) | Filter plate size (mm) | cake thickness (mm) | chamber volume (L) | plate number (pcs) | frame number (pcs) | Filtrating pressure (Mpa) | Weight (kg) | |
BQ1/320-25 | 1 | 320*320 | 25 | 13 | 4 | 5 | 1.0 | 380 | |
BQ2/320-25 | 2 | 25 | 9 | 10 | 500 | ||||
BQ3/320-25 | 3 | 38 | 14 | 15 | 620 | ||||
BQ4/450-25 | 4 | 450*450 | 25 | 51 | 9 | 10 | 0.8 | 1060 | |
BQ6/450-25 | 6 | 76 | 14 | 15 | 1160 | ||||
BQ8/450-25 | 8 | 102 | 19 | 20 | 1360 | ||||
BQ12/450-25 | 12 | 152 | 29 | 30 | 1530 | ||||
BQ16/450-25 | 16 | 203 | 39 | 40 | 1760 | ||||
XQ4/450-25 | 4 | 450*450 | 25 | 51 | 9 |
| 1.0 | 960 | |
XQ6/450-25 | 6 | 76 | 14 | 1140 | |||||
XQ8/450-25 | 8 | 102 | 19 | 1460 | |||||
XQ12/450-25 | 12 | 152 | 29 | 1960 | |||||
XQ16/450-25 | 16 | 203 | 39 | 2460 | |||||
BQ20/630-25 | 20 | 630*630 | 25 | 298 | 24 | 25 | 0.6 | 3300 | |
BQ30/630-25 | 30 | 452 | 37 | 38 | 4500 | ||||
BQ40/630-25 | 40 | 295 | 49 | 50 | 5600 | ||||
BY20/630-25 | 20 | 298 | 24 | 25 | 3700 | ||||
BY30/630-25 | 30 | 452 | 37 | 38 | 5000 | ||||
BY40/630-25 | 40 | 595 | 49 | 50 | 6100 | ||||
XQ20/630-25 | 20 | 25 | 248 | 24 |
| 0.8 | 3400 | ||
XQ30/630-25 | 30 | 377 | 37 | 4700 | |||||
XQ40/630-25 | 40 | 496 | 49 | 5900 | |||||
XY20/630-25 | 20 | 248 | 24 |
| 3800 | ||||
XY30/630-25 | 30 | 377 | 37 | 5200 | |||||
XY40/630-25 | 40 | 496 | 49 | 6400 |
frame and plate cast iron filter plate
application scence,
Some of our hot sale filter and separation equipment as following:
High temperature cast iron filter press for waste oil
High temperature cast iron filter press for waste oil
High temperature cast iron filter press for waste oil
