Product Details
Condition: | New | Automatic Grade: | Semi-Automatic | Production Capacity: | 40m2 |
Place of Origin: | Henan, China | Brand Name: | Toper | Model Number: | BY40/630-25 |
Voltage: | 380V | Power(W): | 2.2kw | Weight: | 6100KG |
Dimension(L*W*H): | 4210*1150*1100mm | Certification: | CE Certificate | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Toper the top three filter press equipment machinery company of China ,cast iron press filter for sale
Brief introfuction of the High temperature filtration cast iron filter press
High temperature filtration cast iron filter press is precisely made by high quality cast iron and nodular cast iron. It is suitable for filtrating high temperature material with high strength filter plate, high pressure filtrating load, long service life. It can be widely used to separate solide and liquid in petroleum chemical industry, metallurgy, grease and ceramic industries.
Working principle of the High temperature filtration cast iron filter press
Filtration is the separation of a fluid-solids solution involving the passing of this mixture through a porous barrier which
retains most of the solid particulates contained in the mixture.
The liquor is either pushed through the filter under pressure. The types and
configurations of filters vary widely; each has its own method of filtering, its own
method of discharging the filtrate and discharging the cake.
Depending on the product, sometimes the filtrate is the desired product and other
time the cake is the desired product.
Two basic structure of the High temperature filtration cast iron filter press
Plate and Frame Filter Press
this is an assembly of plates covered with a filter cloth and frames designed to collect
the cake, held together in a press with that has a head plate and tail plate,the press
is closed by a hydraulic pump, or manually in small presses. The plates and frame can
be made of many types of materials, polypropylene is popular.
Chamber filter press
Many times the press has “recessed plates” where two plates form a cavity for
collecting cake eliminating the frame. Filter presses must be opened and the plates
separated to remove the cake.These are batch filters that push the liquor through
the filter under pressure. Once the cake capacity is reached the cake must be
removed before you continue the process.
Some more photos of the High temperature filtration cast iron filter press
Technical paramenters of High temperature filtration cast iron filter press
Specification | Filter area (m2) | Filter plate size (mm) | cake thickness (mm) | chamber volume (L) | plate number (pcs) | frame number (pcs) | Filtrating pressure (Mpa) | Weight (kg) | |
BQ1/320-25 | 1 | 320*320 | 25 | 13 | 4 | 5 | 1.0 | 380 | |
BQ2/320-25 | 2 | 25 | 9 | 10 | 500 | ||||
BQ3/320-25 | 3 | 38 | 14 | 15 | 620 | ||||
BQ4/450-25 | 4 | 450*450 | 25 | 51 | 9 | 10 | 0.8 | 1060 | |
BQ6/450-25 | 6 | 76 | 14 | 15 | 1160 | ||||
BQ8/450-25 | 8 | 102 | 19 | 20 | 1360 | ||||
BQ12/450-25 | 12 | 152 | 29 | 30 | 1530 | ||||
BQ16/450-25 | 16 | 203 | 39 | 40 | 1760 | ||||
XQ4/450-25 | 4 | 450*450 | 25 | 51 | 9 |
| 1.0 | 960 | |
XQ6/450-25 | 6 | 76 | 14 | 1140 | |||||
XQ8/450-25 | 8 | 102 | 19 | 1460 | |||||
XQ12/450-25 | 12 | 152 | 29 | 1960 | |||||
XQ16/450-25 | 16 | 203 | 39 | 2460 | |||||
BQ20/630-25 | 20 | 630*630 | 25 | 298 | 24 | 25 | 0.6 | 3300 | |
BQ30/630-25 | 30 | 452 | 37 | 38 | 4500 | ||||
BQ40/630-25 | 40 | 295 | 49 | 50 | 5600 | ||||
BY20/630-25 | 20 | 298 | 24 | 25 | 3700 | ||||
BY30/630-25 | 30 | 452 | 37 | 38 | 5000 | ||||
BY40/630-25 | 40 | 595 | 49 | 50 | 6100 | ||||
XQ20/630-25 | 20 | 25 | 248 | 24 |
| 0.8 | 3400 | ||
XQ30/630-25 | 30 | 377 | 37 | 4700 | |||||
XQ40/630-25 | 40 | 496 | 49 | 5900 | |||||
XY20/630-25 | 20 | 248 | 24 |
| 3800 | ||||
XY30/630-25 | 30 | 377 | 37 | 5200 | |||||
XY40/630-25 | 40 | 496 | 49 | 6400 |
We provide you reliable and fast package and variety kinds of transportation way to insure you get the goods in time and safely.
1.We have professional person on line to advise you the most suitable type of machie according to your requirement.
2.Provide you comprehensive.easy-understanding and detail information and technical data about the machie you interested;solve your confusions or questions about the machine
3.Arrange the schedule if you pay a visit to our factory.
Toper the top three filter press equipment machinery company of China ,cast iron press filter for sale
Toper the top three filter press equipment machinery company of China ,cast iron press filter for sale
Toper the top three filter press equipment machinery company of China ,cast iron press filter for sale
