Pressure holding hydraulic filter press, membrane filter press with lower moisture
- 10 Set / Sets per Month
- Qingdao Shanghai Tianjin
- T/T L/C D/P D/A Credit Card PayPal
- Small Efficient vertical automatic laboratory belt filter press with advanced design
- China professional manufacturer fruit belt press filter
- belt extractor for press juice from fruit and vegetables
- Automatic fruit press belt equipment apple juicer machine
- Ion Exchange Nozzles for Intermediate Plate
- CHAMBER FILTER PRESS
Product Details
Condition: | New | Automatic Grade: | Automatic | Production Capacity: | 60m2 |
Place of Origin: | Henan, China | Brand Name: | TOPER | Model Number: | XG60/1000-30U |
Voltage: | 380V/220V | Power(W): | 2.2kw | Weight: | 4.0t |
Dimension(L*W*H): | 4730*1390*1700mm | Certification: | CE | Warranty: | 12months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Pressure holding hydraulic filter press, membrane filter press with lower, moisture
Our company produces various models of recessed filter press and plate-frame mechanical filter press, hydraulic filter press, membrane filter press and full-automatic filter press and filter press spare parts. And membrance filter press has received a very good reputation.
Membrane filter press consists of membrane plate and filter chamber made of ordered filter plates. The slurry materials are sent to filter chamber by the pressure of feeding pump and then go into filtrating media(filter cloth) to separate solid and liquid in slurry material.When solid in slurry material becomes cake shape, air is sent to membrane to fully squeeze the solid to reduce moisture content. If users have high requirement about filtration of sticky material and moisture content ratio, this machine has its own special characteristics to meet the need.
Features of membrane filter press:
1. Frame consists of thrust plate, pressing plate, base, oil cylinder body and main beam etc.
2. The PP membrane filter plate with fratures of good mechanical performance, stable chemical properties, light-weight, smooth and flat surface, good sealing, easy-to-wash etc.
Applications of membrane filter press:
Commodity and Specialty Chemicals
Pharmaceutical Raw Materials and Intermediates
Food Products and Ingredients
Clay and Ceramic Powders
Dyes and Pigment
Industrial Waste Dewatering and Recycling
Oil industry
Technical paremeters of membrane filter press:
Type | Filter area(m2) | Plate size(mm) | Filter chamber volume(L) | Cake thickness(mm) | Number plate(pcs) | Filtration pressure | Motor power(Kw) | Weight(t) | Dimensions(mm) |
XG30/800-30U | 30 | 800*800 | 460 | 30 | 23 | 0.6 | 2.2 | 2.68 | 3120*1390*1700 |
XG40/800-30U | 40 | 595 | 29 | 3.05 | 3510*1390*1700 | ||||
XG50/800-30U | 50 | 748 | 37 | 3.47 | 4150*1390*1700 | ||||
XG60/800-30U | 60 | 902 | 45 | 4.00 | 4730*1390*1700 | ||||
XG70/800-30U | 70 | 1056 | 53 | 4.58 | 5440*1390*1700 | ||||
XG80/800-30U | 80 | 1210 | 61 | 5.08 | 5760*1390*1700 | ||||
XG50/1000-30U | 50 | 1000*1000 | 752 | 27 | 0.6 | 4.0 | 4.35 | 4430*1500*1800 | |
XG60/1000-30U | 60 | 908 | 33 | 4.80 | 4890*1500*1800 | ||||
XG70/1000-30U | 70 | 1063 | 39 | 5.26 | 5350*1500*1800 | ||||
XG80/1000-30U | 80 | 1219 | 45 | 5.72 | 5800*1500*1800 | ||||
XG100/1000-30U | 100 | 1505 | 57 | 6.55 | 6710*1500*1800 | ||||
XG120/1000-30U | 120 | 1816 | 69 | 7.47 | 7466*1500*1800 |
According to customer special requirements, our company can produce non-standard models and suitable for your needs .
Application sites,
Various filter and separation equipment in our factory.
