Features of charcoal briquette making machine
(1) Positioning system: Lantian series charcoal briquette press machine has distinctive positioning system, can position accurately once.
(2) Copper sheathing: Copper is more durable than other materials, so every Lantian coal briquette machine use copper to lengthen machine service time.
(3) Customized service: Moulds can be customized according to customers special demands.
(4) Strict quality control system: We have strict quality control system from purchasing to manufacturing, from a small screw to machine materials.
(5) Enough spart parts supply: Our spare parts are manufactured standardized in batch, so you can get them easily and convenient in future.
(6)Factory but not trading company: We are a 30 years factory, but not trading company, all machine are designed and manufactured by ourselives, so we can guarantee product quality better.
Lantian series molds are multifarious(below are some of them), also can be customized according to your demands. Besides, molds can be changed easily. Changed into different molds, you can get different products.
As the picture show, every machine has two punching needles, which can press twice, so the finished briquettes have higher density. Also another function of the second punching needle is adding combusion improver just on the surface. With combusion improver, the charcoal or coal briquettes can be instant ignited.
(1)Coal briquette machine production line:
Coal powder---binder mixer---crusher and mixer---conveyor belt---dosing machine---briquette machine---dryer
(2)Charcoal briquette machine production line:
Carbonization furnace---charcoal crusher---binder mixer---wheel mill---conveyor belt---dosing machine---briquette machine---box dryer.
The classification
(1)Take 140 for example, 140A and 140B, 140A is a semi-closed briquette machine, 140B is a total-closed briquette machine, but same funtion, max diameter of the briquettes that the machine can produce is 140mm. Changed moulds, the shapes and sizes can be different. Usually the height is not exceed 90mm, it can be 70mm, 80mm, 90mm, etc.
(2) Besides, we still have 160, 220, 260 and 300 for customers choosing.
Type |
Motor Power(KW) |
Capacity(pcs/min) |
Weight(t) |
Size of coalball(mm) |
140 |
7.5 |
45 |
1.8 |
Φ140 |
160 |
7.5 |
50 |
2.2 |
Φ160 |
220 |
15 |
40 |
2.5 |
Φ220 |
260 |
15 |
26 |
3.8 |
Φ260 |
300 |
15 |
26 |
3.8 |
Φ300 |
