Brief introduction of hydraulic shisha charcoal press briquette machine:
The "Lantian" hydraulic shisha press briquette machine is a kind of double pressure type preloading automatic rotation, continuous briquetting machine, it is equiped with a hydraulic system, can press all kinds of granular materials into tablets. It is mainly used in shisha charcoal powder, charcoal powder, and coal powder briquetting, also suitable for pharmaceutical, chemical, food, electronic and other instries.
Technical parameters of shisha charcoal tablet press machine:
| Model | LTM-9 | LTM-12 |
| Power | 7.5 kw | 15 kw |
| Capacity | 150--200 kg/h | 200--300 kg/h |
| Pressure | 80 t | 120 t |
| Feeding Material | ≤ 3mm | ≤ 3mm |
| Tablets Size | 20-45 (round), 15-55 (cubic) | 20-45 (round), 15-55 (cubic) |
| Pressure Type | mechanical pressure | hydraulic pressure |
| Weight | 1350 kg | 1500 kg |
1) Crusher:
It is used to crush the charcoal into powdery material for briquetting, the size must less than 2mm, and the smaller, the better the charcoal briquettes. This is the first step of making charcoal coal briquettes, this machine is an environmental protect extraction device, which can totally keep the powdery charcoal, not only can save material, but also protect the environment.
2). Binder Mixer and Wheel Mixer:
Binder mixer is an special equipment for this production line, to make the charcoal powder easily briquetting, and also increase the hardness of the powdery material. Besides, it ca also make the charcoal briquettes easily burning, and the briquettes are smokeless, non-toxic.
Wheel mixer is to mix the charcoal powder with the liquid binder, but also can grind the charcoal powder to increase its hardness and strength of the charcoal briquettes.
Liquid binder mixer
Wheel mixer
3). Auto Feeder:
It is used to feed the raw material into the briquette machine for briquetting evenly, to avoid the conditions that too much material jam the machine or too little material can not briquetting.
4.Box-type dryer for shisha charcoal tablet machine production line:
Material information of shisha charcoal tablet press machine:
1. Applicable raw material: charcoal powder of biomass material such as: sawdust, wood shavings, wood wastes, branches, rice husk, peanut shell, coconut shell, begasse, sediment, cotton stem, corn stalk, corn cob, etc. After carbonization, the charcoal can be used as raw material.
2. The inlet particle size of raw material: it must be less than 2mm.
3. You must add a certain proportion of liquid binder of some kinds of materials for shaping easily, besides, the binder can also increase the hardness of material, and make the briquettes easily burning.
4. The moisture of materials for briquetting must be moderate, the water content should be 12-15%.
Hookah or shisha charcoal tablets:
This kinds of shisha charcoal tablet press machine also can suitable in pharmacy, foodstuff, coal, chemical engineering, metallurgy building materials, refractory, etc, industry.
1) Size and shapes: Size: round: 20-45mm, square: 15-55mm Shape: round, square, restabgle, triangle, cylinder, diamound, cone, etc
you can also put words, logo, like brand, etc, on the tablets.
2) Characteristics: The shisha charcoal tablet press machine use quick burning charcoal technology, can burn from the top to down. Firepower fierce, smokeless, tasteless, non-toxic, long burning time
♥ Before Service:
1. According to our customers special requirements, provide the most suitable project design, process design and the purchase program.
2. Guide customers to choose the best and economical plant, recover investment within short time, and site inspection.
♥ On sale service:
1. Accompany you to check the working conditions of our machines.
2. Inspect the quality of all our machines.
3. Manufacturer the equipments as the contact appears at first time after receive your deposit. Arrange the delivery timely.
♥ After sale service:
1. Send engineers to your site, help you to install and debugging devides, build plant, and training operators, at the same time pass the technology on clay brick production to customers.
2. Guarantee of the equipments quality, maintenance, etc. Solve all the troubles for you timely during your production when receive your call oure-mails.
