The structure:
1) Frame: The whole frame includes cast iron bedplate, motor base. The frame is the main skeleton entity.
2) Transmission part: This part consists of motor power, belt gear, gear, transmission shaft.
3) Feeding part: This part consists of hopper, moving shaft.
4) Punching part: Punching part is the most important in the whole Hookah Charcoal Single Punch Tablet Press Machine,it consists of beam, punch, shaping mold, moving plate etc. When the machine working,gear revolves then drives punch up and down , After shaping powder into different briquette.
5) Conveyor part: This part consists of transmossion rack, belt pulley, holder.
This machine is our latest patented product, because it has large pressure, and the pressure can be adjusted according to different raw materials, so it has good effect of molding, even some raw materialss are not easy to mold.It can also press into good shapes.The whole machine includes main engine, electric control cabinet, hydraulic cylinder and outlet conveyor belt. For 20-43mm different shapes, it can press 9-48pcs/time, 8-20 times/min.
Parameter
Model |
MA140 |
MA160 |
MA180 |
MA220 |
MA260 |
Capacity(pcs/min) |
45-50 |
45-50 |
45-50 |
20-26 |
20-26 |
power |
7.5kw, 4 pole |
7.5kw, 4 pole |
11kw, 4 pole |
15kw, 4 pole |
15kw, 4 pole |
pressure |
20-30 |
20-35 |
25-35 |
30-40 |
35-45 |
Mode of operation |
Punching press |
Punching press |
Punching press |
Punching press |
Punching press |
Diameter of mould |
140mm |
160mm |
180mm |
220mm |
260mm |
Height of final products |
30-90mm, adjustable |
30-90mm, adjustable |
30-90mm, adjustable |
30-90mm, adjustable |
30-90mm, adjustable |
The production
(1)Coal briquette machine production line:
Coal powder---binder mixer---crusher and mixer---conveyor belt---dosing machine---briquette machine---dryer
(2)Charcoal briquette machine production line:
Carbonization furnace---charcoal crusher---binder mixer---wheel mill---conveyor belt---dosing machine---briquette machine---box dryer.
Features
(1) Automatic feeding and discharging system.
(2) Solid crank arms and strengthly pressing.
(3) We can customize the different molds for making different shaped briquettes.
(4) The mold can be easily changed and maintained.
(5) Buffer device for hydraulic pressure machine to avoide any damage of parts caused by overloading.
(6) This Hookah Charcoal Single Punch Tablet Press Machine can manually working or automatic working.
Our service for our customers:
♥. Pre-sale service: design and manufacture machines for you as your special requirements,provide you with project, process design, and purchase programm.
♥. On-sale service: accompany with you to look around our factory, explain the manufacture
process of our machines, and check the working performance of our machines.
♥. After-sale service: engineers are available to install and debugging equipments of the whole
production line, besides, commissioning and training operators on site
Packing and shipping
Waterproof packing with the international export standard.
Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box.
Other Equipment will be packed by Color-Stripes Plastic Cloth.
In accordance with customer's requirements.
