1. Ball Press Machine Description:
The Ball Press Machine is a widely used in many range, this machine can press the raw materials
for pelletize or press ball, such as aluminum powder, active carbon, aluminum oxide, bauxite, causticity
sodium, charcoal, clay ,braize ,coal, cryolite, chemical fertilizer, plastic, lime stone, pigment, urea, etc.
Our Ball Press Machine series can mould different kinds of mineral powder and the shape can be round,
oval, pillow,rectangle,square shapes,just taper by changing mould.The finished products' surface is very
smooth, also the pressure and density can be adjustable.
2. Ball Press Machine Features:
Ball Press Machine has the following advantage :Special designed mandatory feeder. The machine
can press pure powder material with feature of light weight and small density like charcoal powder.
Special designed assistant equipment. It has fully automatic feeding, sending system. Humanized
design makes the machine’s cleaning and maintenance more easily. Special Installation structure
makes the change and repair of parts convenient.
3. Ball Press Machine Work Principle
Ball Press Machine will pass the power on to the two pressure roller through the reducer.The
two sides and roll rotation, in both the rotating roll,Natural materials to enter the ball roll mode,
with the roll rotation, material pressure on a small become larger, When the material to the two
rollers rotating line contact point, the pressure of materials has reached the peak. Tremendous
pressure in the role of line, the materials become a finished product from the powder ball.
Main Technical Paramaters
Model |
Roll Diameter (MM) |
Capacity (T/H) |
Powder (KW) |
ZKBM 290 |
290 |
1-3 |
5.5 |
ZKBM 360 |
360 |
4-6 |
11-15 |
ZKBM 430 |
430 |
6-8 |
18.5 |
ZKBM 500 |
500 |
7-9 |
18.5-55 |
ZKBM 500H |
500 |
7-9 |
20.7-57.2 |
ZKBM 650 |
650 |
10-15 |
37-45 |
ZKBM 650H |
650 |
10-15 |
39.2-47.2 |
ZKBM 750 |
750 |
15-20 |
75-110 |
ZKBM 750H |
750 |
15-20 |
78-113 |
ZKBM 850 |
850 |
20-25 |
90-110 |
ZKBM 850H |
850 |
20-25 |
93-113 |
ZKBM 1000 |
1000 |
25-30 |
90-132 |
ZKBM 1000H |
1000 |
25-30 |
93-135 |
