Professional manufacture 200m trailer used water well drilling machine for sale
- 50 Set / Sets per Month
- Shanghai Tianjin Qingdao or as your request
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Diesel engine 300m depth trailer mounted water well drilling rig
-
CE foundation pile Rotary drilling machine
-
Rotary pile drilling rig of China supplier
-
FD1565 65m hydraulic Rotary drilling rig with CE&ISO
-
High performance Rotary drilling machine with CE ISO
-
China supplier 1000m depth tractor mounted water well drill rig
Product Details
| Condition | New | Type | Other, power head driven drill rig | |
| Power Type | Diesel | Place of Origin | Henan, China | |
| Brand Name | GEC | Model Number | GSD-II Drilling rig | |
| Usage | Water Well | Voltage | Diesel Engine Driven | |
| Power(W) | 40Kw | Dimension(L*W*H) | 5300*2000*7200(mm) | |
| Weight | 3800kgs | Certification | ISO,CE | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Professional manufacture 200m trailer used water well drilling machine for sale
Feature
1. Drill head style with large torque and lifting force;
2. Multiple purposes and multiple functions drilling;
3. Large drill head inside diameter available for many robs;
4. It can drill with mud drilling and air drilling method;
5. Special designed rod structure makes it easy to connect and disconnect;
6. Easy operation and maintenance, high reliability and long service life;
7. Modular design appropriate rods and pumps provided for clients.
Application:
1. Drilling water wells for urban and rural life.
2. Drilling water wells for agriculture irrigation and industries.
3. Drilling for geotechnical survey.
4. Drilling construction engineering holes.
5. Drilling geothermal pump wells.
Technical Data:
Model |
| GSD-Ⅱ | ||
Drill hole diameter (mm) |
| 90-1200 | ||
Hole depth (m) |
| 200 | ||
Drill rod length (m) |
| 3 | ||
Drill rod diameter (mm) |
| Φ60,φ73,φ89,φ95,φ133 | ||
Inside diameter of power head(mm) |
| Φ35,φ60,φ80,φ120 | ||
Dimension(mm) |
| working:4910*2020*6650 | ||
(L×W×H) |
| transporting:6700*2020*2750 | ||
Weight (kg) |
| 3400 | ||
Drilling method | Normal and Reverse circulation for both Mud&Air drilling | |||
Power head lifting speed (m/s) |
| 0.25, 0.15 | ||
P3ower head lifting force(kN) |
| 55.40,94.55 | ||
Main winch single rope tension(kN) |
| 20 | ||
Feed thrust (kN) |
| 2 | ||
Power head rotating speed (r/min) | A(Normal:13-22-48)( reverse:10-17-36) | |||
B(Normal:48-84-184)( reverse:37-65-142) | ||||
Mud pumps |
| LBN20 | ||
Flow (m3/h) |
| 80 | ||
Power type |
| Diesel engine | ||
Rated power (kW) |
| 40 | ||
Supporting form |
| Mechanical Screw | ||
Mask up-down |
| Mechanical Unit | ||
Chassis |
| Trailer-type with two wheels | ||
Various Drilling Tools of diesel engine water well drill rig for water well :
Mud Drilling Method
Air Drilling Method
Factory:
Workshops:
Trade assurance advantages:
1. Quickly lock trusted seller, saving time and energy;
2. Reduce the risk of online purchasing;
3. If there is a trade disputes, you can complain to Alibaba and get benefits compensation.
We are a member of trade assurance on Alibaba, and our trade assurance amount is USD78000.00 Through trade assurance you can 100% payment refund up to trade assurance amount for orders not meeting agreed Delivery or Quality terms.
We also have crawler type and truck mounted drill for option.
GSD-II crawler drill
GSD-II truck mounted drill
GSD-IIA truck mounted drill
