Home > Manufacturing & Processing Machinery > Drilling Rig > Mine Drilling Rig > High Performance Rotary Drilling Machine With CE ISO
US$ 250,000 - 310,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Rotary Drilling Rig, rotary drilling machine
Power Type:
Electric
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or other
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Supplier 1000m Depth Tractor Mounted Water Well Drill RigUS$ 63,000 - 80,000MOQ: 1 Set -
Portable Good Performance Water Well Drilling Machine in StockUS$ 5,100 - 5,800MOQ: 1 Set
-
Multifunctional Hydraulic Reverse Circulation Drilling RigUS$ 84,655 - 99,565MOQ: 1 Set
-
YG Series Hydraulic Engineering Anchor Drilling RigUS$ 20,000 - 50,000MOQ: 1 Set
-
GEC Brand Hydraulic Jet Grouting Drilling Rig With High EfficiencyUS$ 20,000 - 38,000MOQ: 1 Set
Condition
New
Type
Other, Rotary Drilling Rig, rotary drilling machine
Power Type
Electric
Place of Origin
Henan, China
Brand Name
GEC
Model Number
CD856 rotary drilling machine
Usage
Other, Construction project
Voltage
380v, 50Hz, 3 phase
Power(W)
112kw
Dimension(L*W*H)
18350*3200*7392mm
Weight
36000kg
Certification
CE ISO, ISO CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Choose GEC,choose high quality!
High performance Rotary drilling machine with CE&ISO
Application:
It mainly used in construction project of highway, high-speed railway, subway, high building and so on.
Feature:
1.Using telescopic mast, simple structure, easy transportation.
2.The "+"shape axle bed is used to stand column and link arm, so stand column can adjust all around and keep vertical on rough place.
3.Link arm and cylinder form triangle structure to increase the stability.
Technical Data:
| Model | CD856 | |
| Drilling diameter | 600-1600mm | |
| Drilling depth | 56m | |
| Overall dimension | working | 18350*3200*7392mm |
| transporting | 14662*3200*3090mm | |
| Total weight | 36000kg | |
| Engine | model | B5.9-C |
| rated power | 112kw | |
| type | turbocharged direct injection | |
| Rotary drive | Max. torque | 80KN.m |
| rotating speed | 1-22rpm | |
| Crowd cylinder | Max. push | 150KN |
| Max. pull | 100KN | |
| Max. stroke | 2000mm | |
| Main winch | Max. line pull | 120KN |
| Max. line speed | 70m/min | |
| Rope diameter | 24mm | |
| Auxiliary winch | Max. line pull | 60KN |
| Max. line speed | 50m/min | |
| Rope diameter | 18mm | |
| Mast angle | forward and back | 0-93° |
| left to right | ±3° | |
| Electric controller(opational part) | Long distance monitor system | |
| Drilling record system | ||
| On car printer | ||
| Chassis | Chassis modality | customized |
| Max. travel speed | 2.0km/h | |
| Min. ground clearance | 500mm | |
| Track width | 800mm | |
| Hydraulic system pressure | 300bar | |
