Diesel Engine Concrete Curb Machine Manufacturer
- 50 Set / Sets per Month
- Shanghai Qingdao Tianjin or Other China Port
- T/T L/C D/P D/A Credit Card
Product Details
Condition: | New | Type: | Other, Paving Block Making Machine, Concrete Curb Machine | Brick Raw Material: | Concrete |
Processing: | Other, Concrete Curb Machine | Method: | Autoclaved Aerated Concrete | Automatic: | Yes |
Capacity: | 2-3m/min | Place of Origin: | Henan, China | Brand Name: | GEC |
Model Number: | GDHM21D | Voltage: | No | Power: | 8.0Hp/3600rpm, 8.0Hp/3600rpm |
Dimension(L*W*H): | 2220*920*980mm | Certification: | CE ISO or Other Certificate | Warranty: | 1 year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Diesel Engine Concrete Curb Machine Manufacturer
This is a new kind concrete curb machine, hammer feeding, with manual and
automatic control system. It is a high-tech machinery, integrative technique of
electronics-hydraulics, with advanced sensors, the machine itself can adjust the
level and straight, makes the construction easily. Molds can dismantle and change
in order to meet the construction requirements.
Advantages:
1) with domestic and oversea famous diesel(KIPOR 186F) or petrol engine(HONDA GX390).
2) Import high precision hydraulic valve, compact and saving energy.
3) Import automatically walk precision sensor, error is less than 1mm.
4) With a electronic lever sensor, automatically balance from left and right, water lever back-up observing.
5) Import high protective rank control button.
6) We can customize kinds of specification molds.
Diesel Engine Concrete Curb Machine Manufacturer
Diesel Engine Concrete Curb Machine Manufacturer
Model | GDHM21D |
Working | |
Working Type | Walk-behind Type |
Work Speed | 2-3m/min |
Work Mold | As per customer’s requirement. |
Engine | |
Diesel Model | KIPOR 186F |
DieselType | Diesel engine, air-cooled, 4 stroke, vertical type, single cylinder. |
Power | 8Hp/3600rpm |
Fuel Tank Volume | 5.5L |
Lubricant L | 1.65L |
Fuel Consumption | 280g/kWh |
Machine Size | 2220*920*980mm |
Package Size | 2300*1040*1200mm |
Weight | 700kg |
Diesel Engine Concrete Curb Machine Manufacturer
GDHM21 Modes Drawings of concrete curb machine (the two is for customer reference, we have many different modes drawings for customer choose.)
Diesel Engine Concrete Curb Machine Manufacturer
GDHM11 Hand Push Concrete Curb Machine Manufacturer
1. Describe:
Concrete curb machine is compact and easy to operate, screw extrudes the concrete to make curbs,
save time and effort, specially the the curb of the gardens. Parks, community and flower bed.
2. Advantages:
1) With famous brand engine, reliable performance, easy to start-up.
2) With spiral feeding hopper, the counter force drives the machine backward walking.
3) With walking indicator to insure the correct direction.
4) Mold is easy to dismantle, and can be designed as per customer’s requirement.
5) Plastic treated, anti-rust and beautiful.
3. Picture:
4. Technical Parameters:
Model | GDHM11 |
Working | |
Working Type | Walk-behind Type |
Work Speed | 1-2m/min |
Work Mold | As per customer’s requirement. |
Engine | |
Gasoline Model | HONDA GX160 |
Gasoline Type | Gasoline engine, air cooling, 4 stroke, OHV, single cylinder. |
Power | 5.5Hp/3600rpm |
Fuel Tank Volume | 3.6L |
Lubricant L | 0.6L |
Fuel Consumption | 313g/kWh |
Machine Size | 1500*720*1100mm |
Package Size | 1540*790*910mm |
Weight | 160kg |
