Made In China Diesel Engine Kerb Machine
This is a new kind of kerb machine, hammer feeding, with manual and automatic
control system. It is a high-tech machinery, integrative technique of electronics-
hydraulics, with advanced sensors, the machine itself can adjust the level and
straight, makes the construction easily. Molds can dismantle and change in
order to meet the construction requirements.
Advantages:
1) with domestic and oversea famous diesel(KIPOR 186F) or petrol engine(HONDA GX390).
2) Import high precision hydraulic valve, compact and saving energy.
3) Import automatically walk precision sensor, error is less than 1mm.
4) With a electronic lever sensor, automatically balance from left and right, water lever back-up observing.
5) Import high protective rank control button.
6) We can customize kinds of specification molds.
Made In China Diesel Engine Kerb Machine
Made In China Diesel Engine Kerb Machine
Model | GDHM21D |
Working | |
Working Type | Walk-behind Type |
Work Speed | 2-3m/min |
Work Mold | As per customer’s requirement. |
Engine | |
Diesel Engine Model | KIPOR 186F |
Diesel Engine Type | Diesel engine, air-cooled, 4 stroke,,vertical type, single cylinder. |
Power | 8Hp/3600rpm |
Fuel Tank Volume | 5.5L |
Lubricant L | 1.65L |
Fuel Consumption | 280g/kWh |
Machine Size | 2220*920*980mm |
Package Size | 2300*1040*1200mm |
Weight | 700kg |
Made In China Diesel Engine Kerb Machine
GDHM21D Modes Drawings of kerb machine (the two is for customer reference, we have many different modes drawings for customer choose.)
Made In China Diesel Engine Kerb Machine
GDHM11 Hand Push Kerb Machine
1. Describe:
Kerb machine is compact and easy to operate, screw extrudes the concrete to make curbs,
save time and effort, specially the the curb of the gardens. Parks, community and flower bed.
2. Advantages:
1) With famous brand engine, reliable performance, easy to start-up.
2) With spiral feeding hopper, the counter force drives the machine backward walking.
3) With walking indicator to insure the correct direction.
4) Mold is easy to dismantle, and can be designed as per customer’s requirement.
5) Plastic treated, anti-rust and beautiful.
3. Picture:
4. Technical Parameters:
Model | GDHM11 |
Working | |
Working Type | Walk-behind Type |
Work Speed | 1-2m/min |
Work Mold | As per customer’s requirement. |
Engine | |
Gasoline Model | HONDA GX160 |
Gasoline Type | Gasoline engine, air cooling, 4 stroke, OHV, single cylinder. |
Power | 5.5Hp/3600rpm |
Fuel Tank Volume | 3.6L |
Lubricant L | 0.6L |
Fuel Consumption | 313g/kWh |
Machine Size | 1500*720*1100mm |
Package Size | 1540*790*910mm |
Weight | 160kg |
