China max.aggregate 20mm small electric motor concrete mixer with pump
1. Description:
Portable concrete pump with mixer is combined by the traditional concrete pump and the mixer together. It achieves full automatic during concrete construction process.
2. Application:
Convey floor heating lightweight foamed cement, mortar, fine aggregate concrete.
Convey greening soil in ecological environment construction.
Convey all kinds of engineering construction in the plain concrete, fiber concrete.
Most suitable for four to six floor buildings, especially in the group buildings, bridges and the small construction sites where need the concrete mixer at the scene.
3. Features:
Mixer and pump in one machine.
Transfer concrete through pipeline. It is fast and safe.
It has small size and suitable for more special environment.
Optional part: cement boom, wireless remote control. This is easy to operate.
Technical data of electric motor concrete mixer with pump :
Items
| Units
| Parameters
| ||
JBT30-P2 | ||||
Whole performance of machine | Max. theo. concrete output
| m3/h | 30 | |
ncrete pumping pressure
| MPa | 10 | ||
Distribution valve type
|
| S Valve | ||
Concrete cylinder diameter×stroke
| mm | 140×1000 | ||
Hopper capacity
| L | 400 | ||
Outlet diameter
| mm | 100 | ||
Power system | Hoist motor power | kw | 5.5 | |
Mixer the motor Power | kw | 4.5 | ||
Water pump motor power | kw | 0.55 | ||
Rated power | kW | 37 | ||
Rotate speed
| r/min | 1480 | ||
Hydraulic system | Circuit type
|
| Open circuit
| |
Pumping system pressure
| MPa | 28 | ||
Mixing system pressure
| MPa | 6-8 | ||
Capacity of oil tank
| L | 370 | ||
| Max. Vertical/Horizontal conveying distance | m | 120/500 | |
Other parameters | Max. aggregate diameter
| mm | 20 | |
Inside diameter of delivering pipe
| mm | 100-80 | ||
Dimensions:length×width×height
| mm | 4200x2300x3150 | ||
Total weight | kg | 4500 | ||
Diesel and electric trailer concrete pump:
Small concrete pump which could pumping concrete and spray concrete.
small peristaltic pump for pumping and spraying concrete:
Forced concrete mixer pump:
We are a professional manufacturer of concrete pump machine, in order to supply a more suitable concrete mixer pump for you, please help us clear on your requirements:
1. what is max.aggregate?
2. what is pump capacity and mixer capacity?
3. what is nveying distance(vertical and horizontal)?
