Help CenterSmall Multi-Layer Stainless Steel Wine Electroplating Filter Press
Related Products
-
Good Performance High Precision Filter Press/filtro Prensa/Solid and Liquid Separation MachineUS$ 8,000 - 20,000MOQ: 1 Set -
Chamber Hydraulic Membrane Filter PressUS$ 8,625 - 9,681MOQ: 1 Set
-
Slaughter House Sludge Dewatering Filter Press EquipmentUS$ 25,600 - 36,596MOQ: 1 Set
-
200 mm Multi-Layer Stainless Steel Plate Beer Filter PressUS$ 1,900 - 5,600MOQ: 1 Set
-
1000 mm Automatical Cleaning Coconut Oil Filter PressUS$ 6,520 - 45,456MOQ: 1 Set
Advantages:
1. full stainless steel
2. corrosion-resistant durability
3. Flexible application
4. high temperature, non-toxic, no leakage, good sealing performance
Application:
Used for solid-liquid separation of a variety of suspension. Applied widely in pharmacy industry, food and beverage industry, wine and beer making, chemical industry, water processing, textile industry, environment protection, and so on.
Working principle:
Suspension is pumped into every closed room, under pressure, filtrate go through filter layers, discharge from outlet, leaving residue in the frames to form into filter cakes.
Feature:
* Made of SUS304, SUS316L high quality stainless steel. Corrosion-resisting
* Thread-like filter plate, user could adopt different filter mediums according to different needs
* User could change the number of layers according to filtration yield
* Filtering under pressure sealing, no loss of material liquid, high liquid clarity
* Multi-level filtering system is optional for customize
* All sealing parts adopt silicone rubber seals, nice sealing performance with heat-resisting, non-toxic, non-leakage
* Reflux system is optional for customize
Technical Data electroplating filter :
Item |
Description |
Layer |
10 |
Filtering area |
0.34 m² |
Filter size |
200 mm |
Filter media |
0.8 um |
Filter pressure |
0.15 Mpa |
Water flow |
2 t/h |
Motor power |
1.1 kw |
Weight |
25 kg |
Dimensions |
650x400x700 mm³ |
Our products:
Our factory:
Our cirtification:
