Injection Molding Machine For Cup
Specification
| ZS-258 | ||||
| A | B | C | ||
| Injection Unit | ||||
| Screw Diameter | mm | 50 | 55 | 60 |
| Screw L/D Ratio | L/D | 22 | 20 | 18.3 |
| Theoretical Shot Size | cm3 | 589.0 | 712.7 | 848.2 |
| Injection Weight | g | 536 | 648 | 771 |
| oz | 18.9 | 22.9 | 27.2 | |
| Injection Pressure | MPa | 215 | 178 | 149 |
| bar | 2150 | 1780 | 1490 | |
| Injection Rate | g/s | 150 | 181 | 215 |
| Plasticizing Capacity | g/s | 26.8 | 32.5 | 38.6 |
| Max. Screw Speed | rpm | 150 | ||
| Injection Stroke | mm | 300 | ||
| Clamping Unit | ||||
| Clamping Force | kN | 2580 | ||
| Mold Opening Stroke | mm | 540 | ||
| Tie Bars Clearance | mm | 580×580 | ||
| Max. Mold Thickness | mm | 580 | ||
| Min. Mold Thickness | mm | 220 | ||
| Daylight Opening | mm | 1120 | ||
| Ejector Stroke | mm | 150 | ||
| Ejector Force | kN | 62 | ||
| Ejector Number | piece | 9 | ||
| General Data | ||||
| Max. Pump Pressure | MPa | 16 | ||
| Pump Motor Power | kW | 22 | ||
| Heater Power | kW | 16.65 | ||
| Dimension (L×W×H) | m | 6.09×1.69×2.10 | ||
| Net Weight | t | 8.40 | ||
| Hopper Capacity | kg | 50 | ||
| Oil Tank Volume | L | 240 | ||
Features for Injection Molding Machine For Cup
1 LCD computer control with big display screen
2 Hydraulic proportional valve
3 Generous space for fitting large moulds
4 Large opening stroke
5 Two positon transducers to control clamping and injection
6 4-stage of injection speed, 3-stage of holding pressure, 4-stage of metering phase can be setup according to products' requirement.
7 Optimal platen design, with toggle junction casting together with platen improves rigidity of mechanical system hence improves product dimensions accuracy
8 Screw and barrel are made of high quality new materials, which extended the service life
9 Screw back pressure control
10 Multiple hydraulic ejection
11 Differential area high speed clamping
12 centralized lubrication system
13 All hydraulic components and seals are offered by famous international manufacturers
14 Mechanical safety interlock
15 Electrical safety interlock
16 Oil return filter
The ZS plastic injection machine with variable pump series is the fine product of energy saving of Guangsu Company, which adopt the advanced international control technology of variable pump. The product adopts high response proportional variable system, making the output power of hydraulic system of plastic injection machine matching with the actual consumption, avoiding the loss of high pressure regulated flow and overflow. Compared to the machine with common constant flow pump, 30%50% electricity can be saved, showing obvious economic benefits.
In addition, the heat produced by the machine is low, reducing around 30% cooling water consumption, reducing noise around the machine, extending the service life of hydraulic seals of oil circuit and hydraulic oil, reducing greatly the use and maintenance cots of machine, at same time, the strict global environment-friendly requirements are satisfied. The GS-V plastic injection machine with variable pump series brings obvious economic benefits to wide customers relying on its excellent performance.
The ZS plastic injection machine with variable pump series shows its excellent performance as below:
Energy saving 30-50%;
Quick response of system, short shaping period;
The oil temperature of system reduces greatly the produced heat;
Reduce the mold opening/closing impact, extending the service life of machine and mold;
Extend the service life of oil circuit system, reducing maintenance times, and saving large amount of maintenance cost;
High accuracy demand on hydraulic oil; and high accuracy return filter is provided.
Modernized garden type factory, first-rate hardware equipment,professional science &technology team and perfect management system, ensure the outstanding product performance of "GS".
It is equipped with the modern fashion standard in the aspects of production,design,machining technique,outline design.It lays the greatstress on the development,absorbs and introduces the excellent managing concepts,studies and develops the top grade skill and technology,fosters the professionally qualified personnel.Executing one-stop service and special-people responsible system to the sale,design,installation,troubleshooting and maintenance,we have accumulated abundant practial experien and products adjustment data.
Following the principle of "Technology oriented,Management innovation,Quality first and Customer uppermost",the company is continuing to enhance the development capacity,focusing on the development of a series of products with leading level at home and surpassing the international level,making it the new highlight of economic growth of the company.At the same time,the company has launched a series of new measures in the aspect of management and quality control,and strengthened the cooperation with the domestic and international scientific research institutes and famous enterprise to build the "GS" brand.Under the leadship of the company,all the staffs have decided to carry on the spirit of "Union,Struugle,Practice,Devotion,Innovation and Development" leading the company to a first-class famous enterprise.
Mars Packing Machinery Steer the flourishing future.We welcome all domestic and international customers to visit us and give us intructions.Just as what we did before,we shall continue to try our level best to provide our customers with professional and considerate service to gain the confidence and support from both the old and new customers.
