Help Center70t Pipelayer PMG70
Related Products
Specifications
1.Good quality,low price.2.World famous brand,and professional service
3.Max.lifting capacity:70t.
PMG70 Side boom
PMG70 side boom adopts the KOMATSU technology special side boom chassis, mainly used in pipe laying, carrying, lowering-in works. The equipment can be used from -20 to + 50 , 3000 m altitude, under 5% containing of sand in the air, and other rainy, snowy, foggy condition. It can work with 20°slope in safety. With rational design, compact structure, the equipment is easy for dispatch and transfer.
Items |
Parameters |
||
Model |
PMG70 |
||
Max. lifting capacity |
70 t |
||
Rated lifting capacity |
59.5 t |
||
Total weight(approx.) |
49.5 t |
||
Shipping dimensions(L×W×H) |
5906×3334×3100 mm |
||
Shipping weight of main set |
36.8 t |
||
Average ground pressure |
88.2 kPa |
||
Min. ground clearance |
550 mm |
||
Max. climbing capability |
20 ° |
||
Ambient conditions |
Temperature:-20°C~50°C; |
||
Engine |
Model |
Cummins NTA855-C360 |
|
Rated power |
239 kW |
||
Rated rotating speed |
2000 rpm |
||
Travelling system |
Chassis |
specialized chassis for side boom |
|
Operation type |
Control rod |
||
Theoretical travelling speed |
3.6/6.6 km/h (Forward 2 gear) |
||
4.4/7.8 km/h (Reverse 2gear) | |||
Track length on ground |
3620 mm |
||
Track width |
760 mm |
||
Number of track rollers |
9×2 |
||
Lifting system |
Luffing type |
Wire rope |
|
Operation type |
Hydraulic joystick |
||
Boom |
length |
7600/8600 mm( 9000mm boom can be supplied upon special order ) |
|
Max. lifting height |
6000/7000 mm |
||
Boom luffing angle |
0~86° |
||
Hook speed (8 MF) |
0-6.6 m/min |
||
Luffing time |
30 s |
||
Application standards |
Q/GDR008-2008,ISO8813-92 |
||
