Help CenterPipelayers PMG40
Related Products
Specifications
1.Good quality,low price.2.World famous brand,and professional service
3.Max.lifting capacity:41t
PMG40 is developed based on high driving performance bulldozer chassis which is mainly used for pipe laying line-up and lower-in in pipeline construction. Compared with normal sideboom refitted from flat frame bulldozer, it possesses outstanding features that the braking system adopts normal closed, maintenance-free brake, high braking security and reliability performance. Hoisting system adopts pre-leading handle with simple & handy operation and excellent jiggle performance.
Items |
parameters |
||
Model |
PMG40 |
||
Max. lifting capacity |
41 t |
||
Rated lifting capacity |
34.9 t |
||
Total weight(approx.) |
33 t |
||
Shipping dimensions(L×W×H) |
5110×3390×3300 mm |
||
Shipping weight of main set |
28 t |
||
Average ground pressure |
77.8 kPa |
||
Min. ground clearance |
490 mm |
||
Max. climbing capability |
20 ° |
||
Ambient conditions |
Temperature: -20°C~ +50°C; |
||
Engine |
Model |
Cummins NTA855-C280 |
|
Rated power |
175 kW |
||
Rated rotating speed |
1800 rpm |
||
Travelling system |
Chassis |
Self-designed professional chassis |
|
Operation type |
Control rod |
||
Theoretical |
|
3.6/6.6 km/h(Forward 2gear) |
|
|
4.3/7.7 km/h (Reverse 2gear) |
||
Track length on ground |
3150 mm |
||
Track width |
660 mm |
||
Number of track rollers |
7×2 |
||
Lifting system |
Luffing type |
Wire rope |
|
Operation type |
Hydraulic joystick |
||
Boom |
Length |
7500/8500 mm |
|
Max. lifting height |
6100/7100 mm |
||
Boom luffing angle |
0~85° |
||
Hook speed(8 MF) |
0~7.5 m/min |
||
Luffing time |
30 s |
||
Application standard |
Q/GDR 008-2008,ISO8813-92 |
||
