1.Good quality and low price.2.World famous brand,and professional service
3.Max.lifting capacity:30t
PMGY 30 full hydraulic sideboom adopts self-developed specialized chassis for full hydraulic sideboom, electric/hydraulic single control handle, imported famous brand hydraulic components, wide-narrow combined tracks, which possess advantages of low volume, reasonable structure, low ground pressure, high adaptability, sooth & convenient operation, excellent jiggle performance etc.
Item | Main parameters | |||
Model | PMGY30 | |||
Max lifting capacity t | 30 | |||
Rated lifting capacity t | 25.5 | |||
Overall weight ( approximate ) t | 27 | |||
Delivery dimension ( L×W×H ) mm | 5010×3200×3290 | |||
Transportation weight of main set kg | 21800 | |||
Average ground pressure kPa | 58.6 | |||
Min ground clearance mm | 436 | |||
Max climbing capability ° | 20 | |||
Ambient conditions | Ambient temperature range -20 °C -40 °C ; Altitude below 3000m | |||
Engine | Model | Cummins 6BTA5.9 | ||
Rated power/rated rotating speed kW/rpm | 125/2300 | |||
Traveling system | Chassis | Special designed chassis for sideboom | ||
Operational mode | Hydraulic handle | |||
Theoretical travel speed | gear I km/h | 0 ~ 2.3 infinite speed adjustable | ||
gear II km/h | 0 ~ 5.3 infinite speed adjustable | |||
Length of track on ground mm | 3070 | |||
Track width mm | 910 left 560 right | |||
Number of track rollers | 7×2 ( S/F 5×2 pieces , D/F 2×2 pieces ) | |||
Hoisting system | Luffing type | Wire rope luffing | ||
Operational mode | Hydraulic handle | |||
Main boom | Length mm | 7500 | ||
Max lifting height mm | 6590 | |||
Main boom luffing angle ° | 0 ~ 85 | |||
Luffing time s | Boom down : 24 / boom up : 24 | |||
Hook speed (6MF) m/min | 0 ~ 13 | |||
Applied standards | Q/GDR 008-2008 , ISO8813 - 92 | |||
