Automatic Shearing Machine Steel Plate QC12Y-20X4000 With Good Prices

FOB Price

US$ 6,000 - 11,000 / Set

1 Set(Min. Order)

Port Shenzhen
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangxi, China	Brand Name	Xiashijixie
Model Number	QC12Y-20X4000	Condition	New
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Automatic shearing machine steel plate QC12Y-20X4000 with good prices

Product Description

Hydraulic shears is through the use of the main cylinder (fixed to the wall above) do cut down the exercise, nitrogen cylinder return, thus simplifying the hydraulic system, more stable operation. Upper cutter tilting hydraulic shears in the shearing process arc around a fixed axis swing, leverage, fulcrum force is small, can increase the shear blade life, the life of the machine, the machine structure is compact, and the stepless adjustment of the tool carrier itinerary, greatly improve work efficiency.

Specification	Max.shearing thickness	Max.shearing width	Shearing angle	Ram strokes	Back gauge range	Motor power
Specification	mm	mm	°	min	mm	kw
QC12Y-4×2500	4	2500	1°30	18	20-600	4.0
QC12Y-4×3200	4	3200	1°30	18	20-600	5.5
QC12Y-4×4000	4	4000	1°30	12	20-600	5.5
QC12Y-4×5000	4	5000	1°30	10	20-600	5.5
QC12Y-4×6000	4	6000	1°30	7	20-800	7.5
QC12Y-6×2500	6	2500	1°30	18	20-600	7.5
QC12Y-6×3200	6	3200	1°30	14	20-600	7.5
QC12Y-6×4000	6	4000	1°30	12	20-600	7.5
QC12Y-6×5000	6	5000	1°30	10	20-600	7.5
QC12Y-6×6000	6	6000	1°30	7	20-800	7.5
QC12Y-8×2500	8	2500	1°30	14	20-600	7.5
QC12Y-8×3200	8	3200	1°30	10	20-600	7.5
QC12Y-8×4000	8	4000	1°30	8	20-600	11
QC12Y-8×5000	8	5000	1°30	7	20-800	15
QC12Y-8×6000	8	6000	1°30	6	20-800	15
QC12Y-8×8000	8	8000	1°30	5	20-800	15
QC12Y-10×2000	10	2000	1°30	12	20-600	11
QC12Y-10×2500	10	2500	1°30	10	20-600	11
QC12Y-10×3200	10	3200	1°30	10	20-600	11
QC12Y-10×4000	10	4000	1°30	8	20-600	15
QC12Y-12×2000	12	2000	2°	12	20-600	15
QC12Y-12×2500	12	2500	2°	10	20-600	15
QC12Y-12×3200	12	3200	2°	9	20-600	15
QC12Y-12×4000	12	4000	2°	8	20-800	18.5
QC12Y-12×5000	12	5000	2°	7	20-800	22
QC12Y-12×6000	12	6000	2°	6	20-800	22
QC12Y-12×8000	12	8000	2°	5	20-800	22
QC12Y-16×2500	16	2500	2°	8	20-600	18.5
QC12Y-16×3200	16	3200	2°	7	20-600	18.5
QC12Y-16×4000	16	4000	2°	5	20-800	18.5
QC12Y-20×2000	20	2000	2°30	8	20-600	22
QC12Y-20×2500	20	2500	2°30	6	20-800	22
QC12Y-20×3200	20	3200	2°30	6	20-800	30
QC12Y-20×4000	20	4000	2°30	6	20-800	30
QC12Y-25×2000	25	2000	3°	6	20-800	30
QC12Y-25×2500	25	2500	3°	6	20-800	30
QC12Y-25×3200	25	3200	3°	6	20-800	37
QC12Y-30×2500	30	2500	3°30	6	20-800	37
QC12Y-30×3200	30	3200	3°30	5	30-800	45
QC12Y-40×2500	40	2500	3°30	5	30-800	55
QC12Y-40×3200	40	3200	3°30	5	30-800	55

Detailed pictures for your reference
