Vertical CNC Lathe Machine VTC8080
- shenzhen
- T/T L/C D/P D/A Money Gram Credit Card
You May Like
Product Details
| Condition | New | Type | Vertical | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Place of Origin | Guangxi, China | Brand Name | xiashi | |
| Model Number | VTC8080 | Voltage | 380v | |
| Power(W) | 50kw | Dimension(L*W*H) | 2960*3920*3671mm | |
| Weight | 15000kg | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Technical parameters
Model | Unit | VTC3240 | VTC8080 | |
Max. Swing over Bed | mm | φ500 | φ1000 | |
Max. Turning Height | mm | 400 | 800 | |
Max. Turning Diameter | mm | φ320 | φ800 | |
Spindle Nose |
| A28 | A215 | |
Spindle | Speed Range | r/min | 50-2500 |
|
| rating torque | Nm | 450 | 2200 |
Main Motor | (Nomina/30min) | KW | 15/18.5 | 37/45 |
Chuck diameter | inch | 12" | 24" | |
Rapid Speed of X Axis | m/min | 20 | 10 | |
Rapid Speed of Z Axis |
| 20 | 12 | |
Stroke of X Axis | mm | 300 | 800(Vertical tool post) 520(Horizontal tool post) | |
Stroke of Z Axis | mm | 450 | 850 | |
Precision Machining |
| IT6-IT7 | IT6-IT7 | |
Machining the workpiece surface roughness |
| Ra1.6μm | Ra1.6μm | |
positioning accuracy | X-axis |
| 0.016 | 0.018 |
| Z-axis |
| 0.018 | 0.020 |
Repeat Position Accuracy | X-axis |
| 0.005 | 0.0075 |
| Z-axis |
| 0.006 | 0.015 |
The form of standard tool post |
| Horizontal 8 Position | Horizontal 8 Position | |
Tool dimensions | External cutting tool | mm | 25*25 | 32*32 |
| Boring tool | mm | φ40,φ32,φ25 | φ50,φ40,φ32 |
cutterhead whether can nearby select tool |
| YES | YES | |
Machine weight | kg | 6000 | 15000 | |
Machine overall dimensions(L×W×H) | mm | 3220×1843×2543mm | 2960×3920×3671mm | |
Detailed pictures for your reference
If you have any other requirements for the size,please do not hesitate to contact us,or you can advise us your ideas or thoughts for the machine,we can kindly design for you and communicate with you for the details.
