Horizontal Engine Lathe Machine CD6150

Name: Horizontal Engine Lathe Machine CD6150
Brand: Xiashi
SKU: 140990528
Availability: InStock

Guangxi Xiashi Machinery Equipment Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

Xiashi

Model Number:

CD6150

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name Xiashi

Model Number CD6150

Condition New

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Model	CD6150 CD6250	CD6163 CD6263
Max.distance of between centers	1000mm 1500mm 2000mm	1000mm 1500mm 2000mm
Max.swing over bed	500mm	630mm
Max.swing over tool-post	280mm	410mm
Max.swing over gap	750mm	880mm
Bore of spindle	φ85mm	φ85mm
Effective length of gap	240mm	240mm
Taper of bore in spindle	1:20	1:20
Number and range of spindle speeds	12/21~1500rpm	12/21~1300rpm
Number of spindle cross/longitudinal feeds	138	138
Range of spindle longitudinal feeds	0.04~2.23mm/r	0.04~2.23mm/r
Range of spindle cross feeds	0.02~1.12mm/r	0.02~1.12mm/r
Metric thread number/pitches range	32/0.9~40mm	32/0.9~40mm
withworth thread number/pitches range	32/40~1t.p.i	32/40~1t.p.i
Module thread number/pitches range	24/0.45~10mm	24/0.45~10mm
Diametral thread number/pitches range	30/DP 80~1.75	30/DP 80~1.75
Max.travel of cross tool-post	340mm	340mm
Max.travel of upper tool-post	150mm	150mm
Tool post swivelling tool-post	±45°	±45°
Power of apron rapid-travelled motor	250w	250w
Speed of carriage rapid-travelled motor	4000mm/min	4000mm/min
Power of main motor	7.5kw	7.5kw
Power of cool pump	90w	90w
