Home > Manufacturing & Processing Machinery > Machine Tools > Honing Machine > Vertical Cylinder Honing Machine 3MB9817
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New, New
Place of Origin:
Henan, China
Brand Name:
TIMAC
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Precision Valve Seat Boring Machine TL120NegotiableMOQ: 1 Set -
Valve Seat Boring Machine TS60NegotiableMOQ: 1 Set
-
Engine's Valve and Valve Seat Vaccum Tester ZJ45NegotiableMOQ: 1 Set
-
Brake Drum Disc Lathe / Brake LatheNegotiableMOQ: 1 Set
-
TX90 Valve Seat Boring Machine Made in ChinaNegotiableMOQ: 1 Set
Place of Origin
Henan, China
Brand Name
TIMAC
Model Number
3MB9817
CNC or Not
Normal
Voltage
As Customers' Requirements
Weight
1000KG
Dimension(L*W*H)
1640x1670x1920mm
Power(W)
1.5KW
Certification
CE, ISO
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1. Vertical cylinder honing machine;2. Max. hone dia. 25-170mm;
3. Hone depth 320mm;
VERTICAL CYLINDER HONING MACHINE 3MB9817
Features:
1. The machine is mainly used for honing single line engine cylinders and V-engine cylinders of automobiles motor cycles and tractors and also for other machine element holes.
2. The machine table can shift of the fixture change 0°, 30°, 45°.
3. The machine table is easily up and down manually 0-180mm.
4. Reverse precision 0-0.4mm.
5. Select mesh-wire degree 0°-90° or non-mesh-wire.
6. Reciprocating speed of up and down 0-30m/min.
7. The machines reliable performance widely use honing, easy operation and high productivity.
8. Good rigidity, amount of cutting.
| Specification | Unit | 3MB9817 |
| Max. diameter of hol honed | mm | 25-170 |
| Max. depth of hole honed | mm | 320 |
| Spindle speed(4spets) | mm | 120,160,225,290 |
| Stork(3spets) | a/min | 35,44,65 |
| Power of main motor | Kw | 1.5 |
| Power of cooling pump motor | Kw | 0.125 |
| Machine working inside cavity dimensions(LxW) | mm | 1400×870 |
| Overall dimensions(L×W×H ) | mm | 1640×1670×1920 |
| Machine Weight | Kg | 1000 |
