TXM170A, TXM200A, TXM250A Vertical Cylinder Boring Milling Grinding Machine

Zhengzhou Timeway Machine Tool Co., Ltd.
TXM170A, TXM200A, TXM250A Vertical Cylinder Boring Milling Grinding Machine thumbnail-1
TXM170A, TXM200A, TXM250A Vertical Cylinder Boring Milling Grinding Machine photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
TIMAC
Model Number:
TXM170A TXM200A TXM250A
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name TIMAC
Model Number TXM170A TXM200A TXM250A
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. Vertical boring milling grinding machine;
2. Boring dia. 170/200/250mm;
3. Boring/grinding depth: 400/500mm;

Vertical Boring Milling Grinding Machine



* Model: TXM170A, TXM200A, TXM250A;

 TXM170A, TXM200A, TXM250A Vertical Cylinder Boring Milling Grinding Machine



* Related Machines:

    Vertical Boring Machine: T170S, and T170A, T200A, T250A;
    Vertical Boring Milling Machine: TX170A, TX200A, TX250A;



* Features:

This serial model can be widely used in boring automobile engine cylinders, cylinder sleeves of diesel engines and compressors,as well as various high precision holes boring, surface milling grinding of other workpieces.



SpecificationTXM170ATXM200ATXM250A
Max. boring diameterΦ170 mmΦ200 mmΦ250 mm
Max. boring depth400 mm500 mm500 mm
Max. grinding area400×1000 mm
Max. milling area400×1000 mm
Max. drilling & reaming diameterΦ30 mm
Spindle speed120-1200 r/min
Feeding of the spindle14-900 mm/min
Rapid moving speed of the spindle1000 mm/min
Spindle travel700 mm
Distance between spindle end face and table0-700 mm
Distance between spindle axis and carriage vertical plane375 mm
Feed of work table longitudinal32-1350 mm/min
Rapid moving speed of the table longitudinal travel32-1350 mm/min
Max. longitudinal travel of working table1500 mm
Max. cross travel of the working table200 mm
Working table size (W×L)500×1250 mm500×1500 mm
Main motor5.5 Kw
Processing roughnessBoringRa 2.5
MillingRa 3.2
GrindingRa 0.8
Overall dimensions (L×W×H)2600×1630×2300mm
Packing dimensions (L×W×H)2250×1900×2280mm
N.W./G.W.3300/3600 kg3500/3800 kg



Accessories:
