Acrylic CNC Polishing Machines for Furniture Industry

Acrylic Polishing Machine

Our 1350 extended acrylic diamond polishing machine is equipped with a variable frequency electric spindle, a reduction motor, and a stable logic control circuit. This machine significantly improves its operational reliability and safety. Using diamond cutting tools. It precisely cuts the surfaces of organic glass (acrylic) and light guide plates to achieve a mirror-like effect, resulting in a finished product with sharp edges, transparency, smooth finish, excellent straightness, and no dust, low noise, and minimal wear. One machine saves 3-5 man hours and is suitable for precision polishing high-end acrylic and crystal products. It offers exceptionally high product quality and efficiency, making it an essential piece of equipment for acrylic product manufacturers.

Machine material processing thickness: 0-140mm

Specifications:

Machine Colour: Blue + Silver White

Power Requirements: 3kW AC 50-60Hz, 3ph, 220V

Air Supply Requirements: 0.6-0.8MPa

Spindle Speed: 7000-9000 rpm

Total Power: 3.0kW

Processing Speed: 0-10000 rpm

Cutting Speed: 0-1500mm/min

Bevel Polishing: 0°-60°

Depth of Cut: 0-1.5mm

Processing Method: Spindle Feed

Processing Range: 140mm*1300mm

Dust Collection Port Size: 100mm

Machine Dimensions: L2200*W1200*H1550mm

Machine Weight: 1100kg

Applications: Polishing of acrylic, plexiglass, light guide plates, PS/MS, and other materials
