Product Details
Condition: | New | Type: | Horizontal | CNC or Not: | Normal |
Automatic Grade: | Manual | Max. Swing Diameter: | 300mm | Brand Name: | TIMAC |
Model Number: | T-1236 | Voltage: | As customer's Request | Power(W): | 1.1/1.5 KW |
Dimension(L*W*H): | 1850x750x1400mm | Weight: | 540kg | Certification: | CE & ISO |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Mini Muti-function Lathe Machine for sale T-1236
Product Description
Standard accessories:
3 jaw chuck (Φ160mm), MT.#3 Dead center, Changing gears, Taper lever of drill chuck, Oil gun, Oil tray, Tool box with tools, MT5/3 sleeve, Foot stands, Splash guard, Tapered drift, Drill chuck.
Parameter:
Specification | T-1236 | Specification | T-1236 |
* Cutting | * Drilling and Milling | ||
Max.swing over bed | 300 mm | Max.drilling capacity | 25 mm |
Max.swing over cross slide | 180mm | Max.distance from bench to spindle nose | 232mm |
Max.swing over gap | 430mm | ||
Distance between centers | 910mm | Spindle speed steps | Variable speed |
Spindle bore | 38mm | Spindle speed scope | low:100-1000r/min |
Taper of spindle bore | MT5 | ||
Range of spindle speed | 65-1810rpm | Worktable size | 340x120mm |
Range of longitudinal feeds | 0.017-1.291mm / rev | ||
Range of cross feeds | 0.017-0.276mm / rev | Max.travel of spindle quill | 80mm |
Range of metric threads | 0.4-7mm | Taper of milling spindle bore | MT3 |
Range of inch threads | 4-60TPI | Max. End milling capacity | 25mm |
Max.travel of tailstock quill | 100mm | Max.Face milling capacity | 50mm |
Taper of tailstock bore | MT3 | Headstock stroke (Z axis) | 230mm |
Motor power | 1.1 / 1.5kw | Motor | 600w |
Packing size | 1850x750x1400 | Net weight | 130kgs |
Net weight | 540kg/620kg | Asunder packing of mill head |
