5-AXES LINKAGE VERTICAL MACHINING CENTER

Name: 5-AXES LINKAGE VERTICAL MACHINING CENTER
Brand: TIMAC
SKU: 140796348
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Vertical

Brand Name:

TIMAC

Zhengzhou Timeway Machine Tool Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Vertical

Brand Name TIMAC

Model Number VMC500/5axes

5-AXES LINKAGE VERTICAL MACHINING CENTER

Specification		Unit	VMC500/5axes
Travel	X axis travel	mm	650
	Y axis travel	mm	700
	Z axis travel	mm	460
	X axis swing angle	degree	+110~-110
	C axis swing angle	degree	360
	Distance from spindle to table	mm	200~660
Worktable	Worktable size	mm	500
Worktable	Max. load of worktable	kg	400
Spindle	Spindle taper		HSKA63
	Max. speed of spindle	r/min	20~18000
	Spindle rated torque	N.m	78
	Spindle rated speed	r/min	4300
Feeding speed	X, Y axis rapid move	m/min	40
	Y axis rapid move	m/min	32
	X, Y,Z Feeding speed	mm/min	3~20000
	A axis Max. rapid swing speed	r/min	30
	C axis Max. rapid swing speed	r/min	60
Auto-tool changer system	Magazine form		chain
	Tool NO.	pcs	32
	Tool change time
	Max. length of tool	mm	300
	Max. diameter of tool	mm	76/127
	Max. weight of tool	kg	6.5
Motor	Spindle motor	kw	35
	X/Y1/Y2/Z motor	kw	5.37x4
	A axis Torque motor	kw	27.1x2
	C axis torque motor	kw	25.4
	Coolant pump motor	kw	0.75
	Hydraulic pressure station motor	kw	5.5
	Water-coolant pump motor	kw	4.5
	Grease lubrication pump motor	kw	0.025
	Thin oil lubrication pump motor	kw	0.02
	Rotating chip cleaner motor	kw	0.2
Accuracy	X/Y/Z axis positioning accuracy	mm	0.008
	X/Y/Z Repeatability	mm	0.003
	A/C axis positioning accuracy		8"
	A/C Repeatability		3"
Structure size	Height	mm	3700
	Dimension size(Lx W)	mm	5000x3000
	Weight	kg	12000
	Power demand	kw	120
Work environment	Temperature	degree	-5~45
	Relative humidity		0~90%
	Air pressure	Mpa	0.6
	Hydraulic system work pressure	Mpa	10
	Power		50Hz 380V
