With Perkins Diesel Engine 500kva Prime Industrial Commercial Generator
US$ 35,691 - 59,865
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GENOR POWER
Model Number:
GNRP
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UK Silent 150kva Diesel Generator Set With Perkins EngineUS$ 7,585 - 9,865MOQ: 1 Set -
With Perkins Engine 200kw Diesel Generator SetUS$ 15,625 - 25,355MOQ: 1 Set
-
Silent 38kw off Grid Diesel Generator for CottageUS$ 3,589 - 7,595MOQ: 1 Set
-
With Perkins Engine Power Silent Electric Diesel Generator 150kvaUS$ 8,965 - 14,565MOQ: 1 Set
-
20kva Diesel Engine Silent Lovol Small GeneratorUS$ 3,520 - 4,185MOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
GENOR POWER
Model Number
GNRP
Output Type
AC Three Phase
Speed
1500rpm or 1800rpm
Frequency
50Hz or 60Hz
Rated Power
500KVA
Rated Voltage
220V/380V, 230V/400V, 240V/415V
Rated Current
720A
With Perkins diesel Engine 500kva prime industrial commercial generator
500kva Genset specification:
| Set Model | GNRR500 |
| Prime at 50HZ, 40°C ambient | 400KW 500KVA |
| Standby at 50HZ, 40°C ambient | 440KW 550KVA |
| Rated Gen-set output | 230/400V 50Hz |
| Rated Relative humidity | ≤ 60 % |
| Dimension (L×W×H) | 4100×1350×2050mm |
| Weight | 3700kg |
| Fuel consumption 100% prime load | 106 l/hr |
| Total heat radiated to ambient | / |
| Structure of Gen-set | The Gen-set adopt integrative structure, engine is fix on high strength steel basic frame, anti vibration instrument between the engine and basic frame, cooling fan have protecting cap, control cabinet and circuit breaker installed on Gen-set |
| Control system (Optional) | Basic control panel or Advanced control panel with automatically start-up function and other function |
2506C-E15TAG2 specification:
| Engine Brand | |
| Engine Model | 2506C-E15TAG2 |
| Governor/Class | Electronic |
| Cylinder NO. | 6 |
| Engine build | Vertical in-line |
| Fuel spray pattern | direct injection |
| Aspiration | turbocharged, air to air charge cooling |
| Cooling mode | Radiator cooled (enclose water) |
| Bore and stroke | 135x 167 mm |
| Compression ratio | 16.0:1 |
| Displacement | 15.2 litres |
| Engine Prime Power at 1500rpm | 435KWm |
| Engine Standby Power at 1500rpm | 478KWm |
| Start-up mode | 24V, electric |
| Battery capacity | 2 x 12V 128 Ah |
| Starting/Min temperature | / |
| Lubricating oil consumption | Lubricating oil consumption less than 10% Fuel consumption |
| Lubrication oil capacity | 62 litres |
| Coolant capacity – radiator and engine (40°C) | 58 litres |
| Exhaust temp – full load prime | 514°C |
| Exhaust gas flow – full load prime | 81m³/min |
| Exhaust gas back pressure max | 3,0 kPa |
| Air flow – radiator (40°C ambient) | / |
| Pusher fan head (duct allowance) 40°C | / |
| Air intake – engine– full load prime | 30.5m³/min |
| Standard Air intake temp | 25°C |
| Fuel type | #0 Diesel (Natural temperature) |
| Filter system | Adopt whole changeable lubricating oil, fuel filter and air filter |
| Exhaust system | Adopt industrial high efficiency silencer and flexible bellows |
| Engine derating – altitude | / |
Control system:
1. Protection and indication of low oil pressure, High water/Cylinder temperature , over spped, emergency stop, fail start
2. Offer excitation function
3. Idle control and mains sensor stop
4. Speed signal according to generating frequency
5. LCD indicate state of running and alarming
6. Relay output (fuel ,start,stop,idle output)
7. programmabie output, setting alarming ,stop failure, pre-heat and generating failure.
8. In-build watchdog program ensure no corruption
9. Modular structure desing, ABB flame
