Diesel Generator

Packing size: 260x100x170cm by iron crate

Specifications

Diesel generator features:
1) Output: 120KW/150KVA
2) Open type or Silent type, with or without AMF&ATS
3) Four protection

We are professional supplier on gasoline generator, diesel generator, LPG generator, wind power generator from 300W to 1000KW with very good quality and high performance cost ratio. We export generator sets to many countries all around the world, such as South Africa, Norway, USA... etc.



Here is the specifications of our 120KW/150KVA diesel generator set with Ricardo engine and Stamford alternator:

A) Diesel Engine

Model: Ricardo R6105IZLD

Type:water-cooled,4-stroke,direct injection

No.of cylinder:6

Bore X Stroke (mm): 105x125

Displacement(L): 6.96

Induction system: Turbocharged

Rated output (KW): 134

Rated speed: 1500rpm

Fuel consumption (g/kw.h): 215

Cooling method: water-cooled with radiator

Starting method: D.C.24V Electric starting

B) Alternator

Model:STAMFORD-UCI274F

Rated power: 120KW

Rated voltage: 380/220V

Rated frequency: 50HZ

Rated speed (rpm): 1500

Power factor: 0.8 for 3 phase

Phase connection: 3-Phase

Winding connection: 12-wire for 3-phase

Excitation method: Brushless

Insulation class: H

Voltage regulation: AVR

C) Control Panel

Contain:V-meter,A-meter,Frequency-meter,Circuit breaker,Transfer switch,Air breaker,Indicating lamp,Hour meter,etc.



We can also offer gensets with various brand of engines such as Cummins, Perkins, Deutz, Newholland... or other Chinese engines, etc
