High Quality Canned Drink Filling Machine/ Equipment

Name: High Quality Canned Drink Filling Machine/ Equipment
Brand: JIAZHOU
SKU: 140470822
Availability: InStock

US$ 15,000 - 25,000 MOQ: 1 Unit

Key Specifications

Condition:

New

Application:

Beverage, Other, Beverage, Carbonated Drink

Packaging Type:

Cans

Zhangjiagang Jiazhou Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shanghai for canned drink filling machine

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Other, Beverage, Carbonated Drink

Packaging Type Cans

Packaging Material Plastic

Automatic Grade Automatic

Driven Type Electric

Voltage 220V

Power 2.2KW

Place of Origin Jiangsu, China

Brand Name JIAZHOU

Model Number DCGF

Dimension(L*W*H) 2500*1800*2600mm

Weight 3T

Certification CE ISO

After-sales Service Provided Engineers available to service machinery overseas

P/roduct information

Zhangjiagang Jiazhou Machinery Co., Ltd.

Product description

Main Feature:

This filling machine has a compact structure, perfect control system, easy to operate and highly automated.
The parts contact with product is made of quality SUS, anti-corrosive, and easy to clean.
By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
The capping head adopts constant torque magnetic device to guarantee capping quality and impact cap.
This machine has a high efficient cap arranging system, perfect cap feeding and protection device.
Equipped with perfect clean management system to ensure the bottle clean.
Only by changing the star-wheel, can realize to fill the changed bottle shape.
The machine adopts perfect overload protective device can ensure the operator and machine safe.
This machine adopts adjustable frequency converter.
The main electric components, frequency, photoelectric switch, proximity switch, electric control valves all adopt imported components, which can ensure the quality performance.
The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
The electric components and pneumatic components are all introduced from world famous brand products.

Product display

Product Parameters

Model	DCGF 18186	DCGF 24248	DCGF 323212	DCGF 404015	DCGF 505018	DCGF 606020
Head of washing, filling, sealing	18-18-6	24-24-8	32-32-8	40-40-10	50-50-18	60-60-20
Production capacity (bottle/hour)	3000-4000	5000-6000	7000-8000	9000-10000	11000-12000	15000
Suitable bottle diameter(mm)	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml	φ=50-100 H=150-310 330-1500ml
Filling precision	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm	≤±5mm
Motor power	3.84kw	4.1kw	5.6kw	7.5kw	9kw	11kw
Filling pressure	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4	≤0.4
Overall dimension (mm)	2400×1900 ×2300	2800×2100 ×2300	4200×2300 ×2300	5000×2800 ×2400	5900×3100 ×2400	6500×3500 ×2400
Weight(Kg)	3000	4000	5000	7500	9000	11000
