Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filterFilter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

1.RF series filters are used for oil return fine filtration of hydraulic system, which have high
accuracy, multi-function etc. characteristics.

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

2.Filter basic construction
Return filter is composed of filter top cover and bowl,equipped with indicator interface,
it is suitable for -10°C ~ + 100°C mineral oil, lubricating oil, fire resistant oil and  rapidly
 biodegradable oil etc...
2.1 Housing material
Filter housing : Aluminum
2.2 Seals
Perbunan (= NBR)
Viton (= FPM)(Customizable)
2.3 Filter element
Filter medium materialHigh strength carbon steel skeleton
2.4 Optional accessories
CYB-Ilogging indicator<=DC24V;    CY-IIloggingindicator<=220V
2.5 Type of connection
Flanged connection

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

Filter manufacture DFFILTRI RF Series Tank Mounted Return Filter /hydraulic return line filter/return oil filter

DFFILTRI was founded in 1995, since then we devoted ourselves to research, develop and produce many kinds of hydraulic filters, air filters, hydraulic system accessories, cleaning and filtration equipments, pump valve components. DFFILTRI is our brand, which enjoys high popularity and it has successfully achieved the position both in China and across the world.
DFFILTER filtration technology testing center covers a total area of 450 square meters, of which, clean room area of 200 square meters, and cleanliness is up to 100,000 levels. The centre undertakes filtration technology inspection and testing for in-house science research, production and industry service.
On-line particle counter of BETAB-HIAC/POYCO type (8000A/8000S) provided by HIAC/POYCO company in USA, and its supporting machine"Multi-pass test" and "single-pass test" implements ISO16889 new standard and other international standards perfectly.
Testing center also has the developed equiment for filter performance testing, which can make the comprehensive examination for filter element/cartridge performance. These can insure that company's filter with high capacity, long life, high reliable in full compliance with our customer's  requirement.
The testing centre can take 7 tests of hydraulic filter performance evaluation, they are as follows:
ISO 2941 Verification of collapse/burst resistance
ISO 2942 Verification of fabrication integrity and determination of the first bubble point
ISO 2943 Verification of material compatibility with fluids
ISO 3723 Method for end load testing
ISO 3724 Verification of flow fatigue characteristics
ISO 3968 Evaluation of pressure drop versus flow characteristics
ISO 16889 Multi-Pass method for evaluating filtration performance
