HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use

Name: HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use
Brand: bashan
SKU: 139995228
Availability: InStock

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use thumbnail-1

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use thumbnail-2

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use thumbnail-3

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use thumbnail-4

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use photo-1

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use photo-2

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use photo-3

HOT Sale M22x2 Screw Thread Coils/helicoil Thread Insert/for Military Use photo-4

US$ 0.05 - 0.08 MOQ: 200 Pieces

Key Specifications

Get Latest Price

Brand Name:

bashan

Place of Origin:

China

Model Number:

M22x2

Contact Supplier Request Quote Chat Now

Bashan Aero Material Co.,LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjing Qingdao

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name bashan

Place of Origin China

Model Number M22x2

Material:	Stainless Steel	Coating:	Plates The Titanium/cadmium/galvanization
Color:	Red,green, Yellow,original	Model Number:	M22x2
Used:	Building, Automobile Industry, Furniture, Sanitary, Electronics, Traffic.	Thread:	Coarse, Fine
Type:	Free Running Insert	Standard:	Metric
Place Of Origin:	Henan, China (Mainland)	Brand Name:	Bashan

Description
HOT sale M22x2 screw thread coils/helicoil thread insert/for military use

HOT sale M22x2 screw thread coils

Size	M22x2
Length	0.5D=11.0mm,0.75D=16.5mm,1D=22mm,1.5D=33mm,2D=44.0mm
circle	3.9k,6.4k,8.7k,13.6k,18.4k
type	free running insert
material	stainless steel,Alloy
color	original/red/black/green/yellow
coating	plates the titanium/cadmium/galvanization
standard	MERTRIC/UNC/UNF/
drill diameter	22.5mm

Specification1.Free run type: M2X0.4~M60X4mm.
2.Screw-locking type: M2X0.4~M60X4mm.

HOT sale M22x2 screw thread coils

Specification d×p		Nominal length L×d		W	Dz		d0
d	p	×d	L1		min	max
22	2	0.5d	11.00	3.9	26.30	26.80	22.5
		0.75d	16.50	6.4
		1d	22.00	8.7
		1.5d	33.00	13.6
		2d	44.00	18.4

Material	Grade	Temperature Under Used	Tensile Strength Under Room Temperature	Surface
Stainless Steel	0Cr18Ni9	425°C short time 315°C long time	>1400Mpa	No coated Coat lubricant on the surface Coat Cr Coat Ag
	1Cr18Ni9Ti
	1Cr18Ni9
Alloy	Inconelx750 Nimonic90	750°C short time 550°C long time	>1400Mpa	No coated Coat Ag

Products show

Features:
1.Abrasion resistant
2.Corrosion resistant
3.Heat-stable
4.Saving material
5.Increasing the bearing capacity and fatigue resistant of the insert connecting part

HOT sale M22x2 screw thread coils/helicoil thread insert/for military use

Installation tool

Installation Steps
1.drilling 2.tapping 3.put thread in wrench 4.installing
5.breaking 6.finished 7.putting bolt in

Packaging & Delivery

Packaging Details:

inner: plastic bag
outer: paper box or wooden case,depending on the weight
Delivery Detail:

according to the customer's requirement

Our Certifications

1)Passed ISO9001:2008 quality certificate
2)Passed ISO/TS16949:2009 certificate
3)Passed GJB9001A-2001 military quality certificate.
4)Drafted GJB119.1A-119.4A-2001, GJB107-5110-2002, GB/T5330-2003,HB1862-93

Our company

Xinxiang Bashan Aero Material Co., Ltd., affiliated to China Aviation Industry Corporation (AVIC), is a specialized manufacturer with a history more than 62 years. Our main products are metal wire, wire cloth, test sieve, filter element, filter, steel thread insert, steel reed, metal sintered fiber, edm brass wire, screener and other related products. Our company has independent import and export rights. With plant area covering about 50,000 square meters, we employ more than 200 managerial and technical personnels and 800 skilled workers. Since 1986, we have been exporting wire mesh for buyers in USA. Meanwhile, we carry out a strict quality management system in accordance with ISO9001,TS16949,ISO 14001. Bashan has a wide range of products including all kinds of metal wire, wire cloth, filter element, thread insert, screener, etc. There are over hundreds specifications of wire mesh we can supply and we can offer almost everything which is related with wire and mesh

Product Tags: screw thread coils , helicoil thread insert , wire thread insert
