2X2A Optical Switch
OSW-1 × 2 mechanical optical switch, the performance in the industry-leading level. Low insertion loss, small size: L 22.5 × W 11.8 × H 10, is used to dynamically configure the add-drop multiplexer OADM, cross connect OXC, the ideal system monitoring and protection devices. Tiny package more easily integrated into high-density optical communication systems.
Features
Low insertion loss
* Wavelength range
Low channel crosstalk
High stability, high reliability
* Unique patented technology, optical path epoxy
Locking and non locking two control types
Applications
* MAN
* R & D Lab
• System monitoring
Dynamic Configuration drop multiplexing
Model OSW-1 × 2
Wavelength range
nm
670 ~ 980
1260 - 1650
Test wavelength (optional)
nm
670/785/850/980
1310/1490/1550/1625/1650
Insertion Loss
dB
Typ: 0.8 Max: 1.2
Typ: 0.8 Max: 1 .. 0
Return Loss
dB
MM ≥ 30 SM ≥ 50
Channel crosstalk
dB
MM ≥ 35 SM ≥ 55
PDL
dB
≤ 0.05
Wavelength Dependent Loss
dB
≤ 0.25
Temperature Dependent Loss
dB
≤ 0.25
Repeatability
dB
≤ ± 0.02
Operating voltage
v
3.0 or 5.0
Life
Times
≥ 107
Switching time
ms
≤ 8
Optical power transmission
mW
≤ 500
Operating Temperature
℃
-20 ~ +70
Storage temperature
℃
-40 ~ +85
Weight
g
16
Dimensions
mm
L 22.5 × W 11.8 × H 10 (+ / - 0.2)
