PM2×2 Optical Switch
professional supplier of fiber optical component
◇Features
l Low Insertion Loss
l Wide Wavelength Range
l Low Crosstalk
l High Stability, High Reliability
l Epoxy-free on Optical Path
l Latching and Non-latching
◇ Application
l Metropolitan Area Network
l R&D in Laboratory
l System Monitoring
l Configurable OADM
◇ Performance
Parameters |
POSW-2×2 |
|||||||
Fiber type |
nm |
PM630 |
PM1550 |
|||||
Testing Wavelength |
nm |
630/650/780/850/980/1064/1310 |
1310/1490/1550/1625/1650 |
|||||
Insertion Loss |
dB |
Typ:1.0,Max:1.3 |
Typ:1.0 ,Max:1.2 |
|||||
Return Loss |
dB |
≥30 |
≥50 |
|||||
Crosstalk |
dB |
≥35 |
≥50 |
|||||
ER |
dB |
18.00 |
||||||
WDL |
dB |
≤0.25 |
||||||
TDL |
dB |
≤0.25 |
||||||
Repeatability |
dB |
≤±0.02 |
||||||
Power supply |
v |
3.0 or 5.0 |
||||||
Lifetime |
Cycle |
≥107 |
||||||
Switch Time |
ms |
≤8 |
||||||
Transmission Power |
mW |
≤500 |
||||||
Operation Temperature |
℃ |
-40～+85 |
||||||
Storage Temperature |
℃ |
-40～+85 |
||||||
Weight |
g |
16 |
||||||
Dimension |
mm |
(L)28×(W)12.6×(H)8.5(±0.2) |
||||||
