MEMS1×8 Optical Switch
professional supplier of fiber optical component
The MEMS Latch Series 1x8 Fiber optic switch connects optical channels by redirecting
incoming optical signals into selected output fibers. This is achieved using a patent pending MEMS configuration and activated via an electrical control signal. It uniquely features rugged thermal activated micro-mirror movements instead of rotation, and latches to preserve the selected optical path after the drive signal has been removed.
This novel design significantly reduces packaging requirement, and simplifies driving electronics, offering unprecedented high stability as well as an unmatched low cost.
Features
• High Reliability
• Latching
• Intrinsic tolerance to ESD
Applications
• Channel Blocking
• System Monitoring
• Instrumentation
◇ Performance
Parameters |
MSW-1×8 |
|||
Wavelength Range |
nm |
1260～1620 |
||
Testing Wavelength |
nm |
1310/1490/1550/1625/1650 |
||
Insertion Loss |
dB |
Typ:0.7 ,Max:1.2 |
||
Return Loss |
dB |
≥50 |
||
Crosstalk |
dB |
≥50 |
||
PDL |
dB |
≤0.10 |
||
WDL |
dB |
≤0.25 |
||
TDL |
dB |
≤0.20 |
||
Repeatability |
dB |
≤±0.05 |
||
Repeatability Rate |
Hz |
20 |
||
Lifetime |
Cycle |
≥109 |
||
Switch Time |
ms |
≤5 |
||
Transmission Power |
mW |
≤500 |
||
Operation Temperature |
℃ |
-5～+70 |
||
Storage Temperature |
℃ |
-40～+85 |
||
Switching type |
Latching |
|||
Dimension |
mm |
(L)42×(W)26×(H)9.4(±0.2) |
||
