Specifications
High Speed Flexo Printing Machine1.EPC,Auto Tension Control
2.High Speed
3.Have Stock
4.Free technology support
Detail Of YT-4-800 Four Colors Automatic Low Price High Speed Flexo Printing Machine :
This High Speed Flexo Printing Machine Suitable for printing such packing materials as non-woven fabric,polyethylene, polypropylene plastic bag, glass paper,etc. It is a kind of ideal printing equipment for producing paper package, supermarket handbag, vest bag and clothes bag, etc.
Function:
1 Easy operation, flexible starting, accurate color register.
2 The meter counter an set printing quantity according to the requirement,Stop the machine automatically at the quantity,Stop when the material is cut off.
3 Lift and lower the printing plate cylinder manually,it will automatically stir the printing ink automatically after lifting.
4 The printing ink is spread by the cylinder with even ink color.
5 Reliable drying system coordinated with high speed rotation, it will automatically break circuit when the machine stops.
6 360°continuous and adjustable longitudinal register device.
7 The frequency controller of motor speed adapts to different printing speed.
8 there are inching/stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.
High Speed Flexo Printing Machine With Four Color Specification:
Type |
YT-4600 |
TY-4800 |
YT-41000 |
Max. Width of Printing |
550mm |
750mm |
950mm |
Max. Printing Length |
914mm |
914mm |
914mm |
Max Diameter of Printing Length |
Φ450mm |
Φ450mm |
Φ450mm |
Printing Speed |
5-50m/min |
5-50m/min |
5-50m/min |
Printing Color Number |
2.4.6 |
2.4.6 |
2.4.6 |
Format Mater Thickness |
0.02-0.06mm |
0.02-0.06mm |
0.02-0.06mm |
Total Power |
19kw |
19kw |
19kw |
Machine Weight |
3T |
4T |
4.5T |
Overall Dimensions(L×W×H)mm |
3850×1850×2250mm |
3850×2050×2350mm |
3850×2250×2350mm |
Skype: ritayuan99
Trade Manager : cn1000514614
Tel:+0086-13967712895
Flexo Printing Machine Optional Device:
1.PLC
2.Flexo Printing Ceramic Anilox Roll
3.Air Shaft
4.EPC
Flexo Printing SAMPLE:
Blade :
Printing Machine Air Shaft:
Four Colors High Speed Flexo Printing Machine Detail Pictures:
Printing Cylinder:
High Speed Flexo Printing Machine For Plastic Film :
Flexo Machine For Paper Print:
Nonwoven Material Printing:
4 Colors Flexo Printing Machine Real Machine Photos : Printing for Nonwoven
High Speed Flexo Printing Machine Real Pictures:
Customer Come to Our factory to check and Loading the Machine :
Loading Details:
Welcome contact me any time
