Polyester/Mylar Laser Cutter
- Wuhan
- T/T Money Gram
You May Like
Product Details
| Laser Type | CO2 | Place of Origin | Hubei, China | |
| Brand Name | Golden Laser | Model Number | JG-13070DT |
Wooden Case Package
Product Description
Specifications
Polyester/Mylar Laser Cutter1.efficient cutting
2.high-quality cut finish
3.highly intricate cut patterns
4.no tool wear
Polyester/Mylar Laser Cutter
Laser cutting is a non-contact form of cutting that uses a focused laser beam to cut cleanly a variety of materials. We supply state-of-the-art CNC-controlled laser cutting machinery. We laser cut acrylic, Mylar, polypropylene, polyester, and several thin film laminates including printed membrane switch materials, etc.
Laser cutting offers the following key benefits:
- quick and efficient cutting
- high-quality cut finish
- highly intricate cut patterns can be achieved
- the ability to change component designs easily
- Neither tool wear nor tool change necessary in comparison to routing, drilling or sawing
Here we list most of Materials that our laser can cut:
Plastics:
ABS (acrylonitrile butadiene styrene)
Acrylic (also known as Plexiglas, Lucite, PMMA)
Delrin (POM, acetal)
High density polyethylene (HDPE)
Kapton tape (Polyimide)
Mylar (polyester)
Nylon – melts badly
PETG (polyethylene terephthalate glycol)
Polyethylene (PE)
Polypropylene (PP)
Styrene
Two-tone acrylic – top color different than core material, usually for custom instrumentation panels, signs, and plaques.
Foam:
Depron foam – often used for RC planes.
EPM
Gator foam – foam core gets burned and eaten away compared to the top and bottom hard shell.
Other:
Cloths (leather, fabric, textile, suede, felt, hemp, cotton)
Magnetic sheets
Papers
Rubbers (only if they do not contain chlorine)
Teflon (PTFE, Polytetrafluoroethylene)
Woods (MDF, balsa, birch, poplar, red oak, cherry, holly, etc.)
Recommend Model: JG-13070DT Laser Cutting Machine | |
Machine Features: | |
| |
Technical Parameter | |
Laser type: | CO2 glass laser tube |
Laser power: | 50W/65W/80W100W/130W |
Working area: | 1300mm×700mm |
Cutting speed: | 0-24000mm/min |
Cooling system: | Water-cooling and protection system |
Motion system: | Offline stepping control system |
Working table: | Zinc-iron alloy honeycomb working table |
Repeating location accuracy: | ±0.1mm |
Power supply: | AC220V±5% / 50Hz |
Format support: | AI, BMP, PLT, DXF, DST, etc. |
Standard collocation: | Mini air compressor, 550W up & down exhaust fan |
Optional collocation: | Strip panel working table, Automatic control high pressure blower valve, Dual-core system, Constant temperature water-chiller, Servo system |
Working size and laser power can be customized as your requirement. | |
Laser Cutting Samples Gallery:
Golden Laser Exhibitions Worldwide:
Company Profile
Golden Laser, a high-tech enterprise, is committed to providing laser machines and solutions for global customers. (Stock Code: 300220) Product line includes laser cutting machine, laser engraving machine, Galvo laser machine, Co2 flatbed laser cutting machine, metal laser cutting machine, fiber laser cutting machine, yag laser cutting machine, laser marking machine, more than 100 models of laser machines with different types of Co2, YAG and fiber laser. Applications involve textiles, garment, industrial fabrics, advertising, printing, packaging, electric, furniture, decoration, carpets, car interiors, metal processing and other industries. After many years of efforts and innovation, Golden Laser has grown into China great leadership and world-renowned manufacturer of laser equipment. Our marketing network has been extended to more than 100 countries and regions globally. Especially in the textile and garment field of laser applications, Golden Laser has become China's first brand. As a backbone enterprise of China Optical Valley, Golden Laser has research and development centers and a government awarding foreign technical cooperation agencies, and built complete laser equipment manufacturing industry chain. A number of products and technologies obtained national patents and software copyrights. Looking forward to the future, Golden Laser will continue to adhere to the main line of development of the industry breakthrough strategy to continue to strengthen technological innovation, management innovation and marketing innovation as the core of the innovation system advantages. Golden Laser Development Direction For all sectors to provide laser application solution providers and aggregators Integrated laser full industrial chain, providing solution for laser application Providing service for all the enterprises on the laser industry chain Golden Laser Spirit Unity --Great Efforts and Hard Struggle Creativity --Patent and quality Faith --Sincerity and trust Service --Customer priority and consideration
Contact Us
- Wuhan Golden Laser Co., Ltd.
- Contact nameYOYO DING Chat Now
- Phone0086-158-71714482
- AddressGolden Laser Building, Shiqiao 1st Road, Jiang'an District, Wuhan, Hubei, China
