Post Composite Insulator (polymer) - 35KV

Specifications

Post Composite Insulator (polymer) - 35KV
1.Rated voltage:35KV
2.Total Height mm:650-670
3.Usage:suitable for innovation

Post Composite Insulator (polymer) - 35KV



Usage:The product are suitable for the innovation of urban electical network where it can increase the voltage and transport the electricity effectively by using the narrow street.And it can reduce the necessary height of the pole/tower.Due to it’s high stength of bending,it will comepletely avoid the crack case that happened on porcelain crossarm.Moreover,it can be well pollution resistan.



Our Rod Suspension Composite Insulator has many good performances: light weight, high-strength, excellent anti-pollution flashover capability, small size, not easy to break, convinient in fitting and maintenance etc. This kind of insulators have been widely used in over 20 countries all of the world. After long time using in the area where the pollution flashover occurs frequently, composite insulator could still keep fine capability in anti-pollution flashover and anti-wet flashover.



Insulator Mode	Rated Voltage kV	Rated mechanical tensile load Kn	Link structure marker	Structure Height  mm	Minimum distance ArcL.	Minimum nominal Creepage distance mm	Full-wave Lightning Impulse withstand voltage (peak)	Min.wet withstand voltage per minute at power frequency
										Dry	Wet

FXBW2-35/70	35	70	16	650±15	470	810	230	108	95
FXBW4-35/70	35	70	16	650±15	470	1015	230	108	95
FXBW2-35/100	35	100	16	670±15	450	810	230	108	95
FXBW4-35/100	35	100	16	670±15	450	1050	230	108	95
