Product Details
Condition: | New | Automatic Grade: | Automatic | Production Capacity: | 100% |
Place of Origin: | Shanghai, China | Brand Name: | QILEE | Model Number: | QLD201 |
Voltage: | 220v/380v | Power(W): | 400 | Weight: | 375kg, 375kg |
Dimension(L*W*H): | 2300*785*1270(mm) | Certification: | CE | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
low noise dyeing plant wastewater treatment screw press separators
Product Parameter of screw press separators
Parameter | |
Treating Capacity | 3~300(DS-kg/h) |
Power Consumption | 0.2~6.0kw/h |
Cleaning Water Consumption | 24~216L/h |
Macromolecule Polymer Addition Rate | 2.0~4.0(kg/Ton D.S) |
Maintenance Frequency | 5min/day |
Water Pressure | 0.2~0.3MPa |
Distance of Outlet Exit to Gound | 215~500mm |
Replacement Period of Screw Axis | 3~11 year |
Replacement Period of Moving Ring | 1~4 year |
Product Structure of screw press separators
1.The main part of the dehydrator is a filter device that a screw runs through the stacked
fixed rings and moving ring.
2.The small gaps between fixed rings and moving ring can filter the sludge, and the
lumenbetween screw and rings is filled with polymer grains. The moving ring transfers
the sludge to the end of the machine with pressure and extrudes sludge cakes.
3.The running of the screw drives the moving ring to clean the gaps and avoid jam.
Product Features of screw press separators
1.Suitable for sludge dewatering of high/low consistency. When deal with low
consistency sludge(2000mg/L), there is no need to build a thickening tank, storage
pool. Reduce the cost and the release of phosphorus and Anaerobic stink.
2.There is no need to worry about jam up. Reduce the cleaning water consumption.
3.The electrical cabinet, disposal tank and dehydrator are integrated, which reduces
the covering area and brings convenience to installment.
4.The dehydrator is enclosed working, which reduces the bad smell and improves
the working environment.
5.Automatically working for 24 hours, reducing the labor strength of workers.
6.The slow running speed of screw shaft reduces the power consumption and noise.
7. It is made with stainless, extending the service life.
8. It is convenient for daily maintenance.
Product Details of screw press separators
Product Application:
City mixed raw sewage
Food & beverage industry
Chemical industry
Stone & mine sewage
Leather & tannery sewage
Paper & pulp sewage
Elecro-plating sewage
Pringting & dyeing sewage
Power plant
Petrochemical industry
