NDT Inspection/ Testing /measuring/detecting/detection
- xiamen
You May Like
-
Automatic Online ECT Eddy Current Metal Flaw Detector System
-
IDEA-P0701 High-accuracy Weld Crack Flaw Detector
-
Intelligent Metal Material Sorting Instrument/eddy Current Testing Machine
-
Non-destructive Quality Inspection Measurement Equipment/Service/Technology/Manufacturing
-
Eddy Current Crack Depth Finder, Ndt Flaw Detector
-
Non-destructive Tubes/pressure Vessel/boiler/heat Exchanger Test Equipment Manufacturer
Product Details
| Place of Origin | Fujian, China | Brand Name | IDEA | |
| Model Number | IDEAP0101 | Power | Electronic | |
| Usage | Other, pipe, tube , bar etc., Eddy Current Detector/Electrical conductivity / Thickness Gauge |
Product Description
Specifications
1.NDT inspection/ testing /measuring/detecting/detection2.High accuracy inspection :0.05mm
3.Eddy Current testing machine
1.NDT inspection/ testing /measuring/detecting/detection
2.High accuracy inspection :0.05mm
3.Eddy Current testing machine
NDT Eddy Current testing machine is a functional and ingenious appearance eddy current testing instrument from IDEA company . It has small volume, light weight, High-Resolution colorful LCD, adjustable phase, gain and Test Frequency, applies to almost all the eddy current testing , and has English and chinese operating interface, can master the operation quickly , so it is the first choose for the engineer.
Applications of NDT Eddy Current testing machine :
|
| Weld Inspection Check the integrity of welds on steel structures such as bridges, ships, oil rigs and steel framed buildings. Cracks can be detected through surface coating materials such as paint, so minimal time and money is needed for preparation. |
Crack and Corrosion Detecting:
|
Surface crack of Ferromagnetic or non-Ferromagnetic metals
|
Subsurface crack and corrosion of non-Ferromagnetic metals
|
Tube and bar material Detecting:
|
| Absolute and differential type be carry on an examination in the meantime, can accurate valuation the corrosion and examine the small blemish in a tube material also. |
| Choose of Non-Ferromagnetic metals: Measuring the electric conductivity of material to determinant grade of material and the quality of material. |
Specification of this NDT Eddy Current testing machine
|
Large screen, high luminance 5.7 inch colored TFT-LCD
|
Frequency range: 50Hz~5MHz, step length: 1/5/10 adjustable
|
Benefit: 0 dB ~99dB, step length: 0.5 dB
|
Phase: 0~ 359 degrees, step length: 1 degree
|
Probe driver: Absolute, differential
|
Display usage: Impedance, time-base scanning
|
Digital filter: qualcomm frequency (0HZ~2000HZ), Low-pass frequency0Hz2000Hz
|
Store 10 groups inspecting technics parameter
|
Store 10 graphics(which can be expanded to 10,000),the graphics can be restored in a USB
|
PC communication: USB 2.0 and RS-232
|
Operation system: Linux 2.6, easy to operate
|
Operation system language: Chinese, English
|
Online hotkey graphics, text help
|
Build-in rechargeable lithium battery 8000MAH
|
Coordinate system : Rectangular coordinate system
|
Center coordinates: Adjustable
|
Show the calendar, time and capacity of battery automatically
|
Charging power range: 110V220V20, 20 50 60Hz
|
Working temperature: -10~ 50
|
Instrument volume: 210 MM x 130 MM x 90 MM
|
Instrument weight: 2.0KG
|
