Visible Spectrophotometer 722S (340-1000nm)

Name: Visible Spectrophotometer 722S (340-1000nm)
Brand: graigar
SKU: 130807603
Availability: InStock

Shenzhen Graigar Technology Co., Ltd.

US$ 480 - 600 MOQ: 1 Piece

Key Specifications

Brand Name:

graigar

Model Number:

722S

Size:

450X420X280mm

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Brand Name graigar

Model Number 722S

Size 450X420X280mm

Weight 8kg

Wavelength Range 340 to 1000nm

Specifications

Visible Spectrophotometer 722S (340-1000nm)

Applications and Features:

722S Spectrophotometer is a compact and easy to operate instrument. It can be applied in measurement of

transmittance, absorbance and direct concentration readout of transparent material. They have been versatility

employed in the fields of hygiene and medicine, clinical examination, biochemistry, petrol chemical engineering,

environmental monitoring and inspections, and quality controls for qualitative and quantitative analysis of concerning

samples.

Features

1. Aspherical light source optics, Curny-terner configuration diffraction grating monochromator.

2. Simple & clear keyboard operation is convenient to realize auto 0% T &100% T adjustment T/A transformation,,

factor setting and direct concentration readout function.

3.With RS232 parallel l interface,

4.With RS232 serial interface,micro printer can be chosen for printing data directly;

data processing package compatible,Transmittance and Absorbance ,Standard Curve Mode ,Quantitative Analysis

Mode are provided.

5.Spacious sample compartment, 4 position cell rack, adaptable for 1-5 cm optical path rectangular cells.

Specifications:

Model	722S
Wavelength Range	340-1000nm
Light Source Lamp	Halogen-Tungsten Lamp 20W/12V
Wavelength Accuracy	+/-2.0 nm
Wavelength Reproducibility	1 nm
Band width	6 nm
Photometric Accuracy	+/-0.5%(T)(SRM930D)
Photometric Reproducibility	0.2%(T)
Stray Light	<=0.5%(T)
Noise	+/-0.5%(T)
Scale Display	TRANS:0-199.9% ABS:-0.3-2.999 FACT:1-9999 CONC:0-9999
Power Requirement	220V/110V +/-10% , 50/60 Hz
Interface	RS232 serial & parallel interface
Print	serial printer/general printer(windows compatible; use software package )
