SADT Portable Ultrasonic Flaw Detector SUD10
Description:
SUD10 Portable Ultrasonic Flaw Detector is a portable, microprocessor-based instrument suitable for both workshop and field use.
SUD10 is integrated with international advanced digital integration and new EL display technology, is a smart Digital Ultrasonic Flaw Detector propelled by SADT.
SUD10 has almost all functions to meet requirements of professional application for non-destructive testing.
Features:
· Automatic calibration of transducer Zero Offset and/or Velocity
· Automatic gain,Peak Hold and Peak Memory
· Automatic display precise flaw location (Depth d,level p,distance s,amplitude,szdB,)
· Automatic switch three staff gauge ((Depth d,level p,distance s)
· Ten independence setup, any criterion can be input freely, we can work in the scene without test block
· Big memory of 300 A graph and 30000 thickness value.
· B scan
· RS232 port,communication with pc is eas
· The embeded software can be online updated
· Li battery, continue working time up to 8 hours
Other assistant function:
· Display freeze
· Automatic echo degree
· Angles and K-value
· Lock and unlock function of system parameters
· Dormancy and screen savers
· Electronic clock calendar
· Two gates setting and alarm indication
· High-speed capture and very low noise
· DAC,AVG,B Scan;Solid metal housing (IP65)
· Automatically make video of test process and play
· Provides high contrast viewing of the waveform from bright, direct sunlight to complete darkness and easy to read from all angles
· Powerful PC software and data can be exported to Excel
Warranty:
One year warranty, battery not included.
Standard package:
SUD10 main body
Straight probe
Angle probe
Probe connection cable
Data managing software
Interface cable
Operation manual
Carrying case
Specifications:
| Title | Parameter |
Title |
Parameter |
| Measuring range(mm) | 2.5 ~ 10000 | Measurement mode | single,dual,THRU |
| Vertical linearity error | ≤2.5% | Reject | 0-80% |
| Horizontal linearity error | ≤0.1% | Pulse shift(μs) | -20 ~ +3400 |
| Sensitivity margin | ≥60dB | Zero(μs) | 0.0 ~ 99.99 |
| Dynamic scope | ≥32dB | Port type | BNC |
| Resolution | ≥40dB | Operating temperature | -20~50 |
| Frequency range(MHz) | 0.5 ~ 20 | H×W×D(mm) | 240×180×50 |
| Gain(dB) | 0 ~ 110 | Weight(kg) | 2.2 |
| Velocity | 1000 ~ 13000 | -- |
