Rigol DS1074B 70MHz,4 channel desktop Digital Oscilloscope,Digital oscillograph
Model |
DS1204B |
DS1104B |
DS1074B |
Bandwidth |
200 MHz |
100 MHz |
70 MHz |
analog channels |
4 |
||
Real-time sampling rate |
2 GSa / s (half channel *) 1 GSa / s (per channel) |
||
Equivalent sampling rate |
50 GSa/s |
25 GSa/s |
10 GSa/s |
Memory depth |
16 kpts (half-channel) 8 kpts (per channel) |
||
Standard Interface |
USB Host (2) & Device, LAN |
||
Optional Interface |
USB-GPIB Adapter |
||
Product Category |
Desktop Digital Oscilloscope |
||
Dimensions |
W × H × D = 325mm × 159mm × 133mm |
||
Weight |
3 kg |
||
Note: "semi-channel" for CH1 / CH2 only select one, or CH3 / CH4 only select one | |||
Product Overview
DS1000B series for dual-channel / 4 channels plus an external trigger input channel digital oscilloscope, which can capture the multi-channel signals to meet industrial application requirements. DS1000B series of powerful triggering and analysis capabilities make it easy to capture and analyze waveforms. A clear liquid crystal display and math functions, faster and more user-friendly observation and analysis of the signal clearly.
Features
1. To provide 4 analog channels, the maximum 200MHz bandwidth, 2 GSa / s real-time sampling rate and 50GSa / s equivalent sample rate
2. 5.7-inch QVGA (320 × 240), 64k color TFT color LCD display, LED backlight technology
3. With waveform storage, set up storage, 8-bit bitmap, 24-bit bitmap, PNG storage, CSV storage
4. Edge, pulse width, video, code type, alternate triggering
5. A rich interface configuration: Standard Dual USB Host, USB Device, LAN (LXI-C type standard), optional USB-GPIB
Software Features
Ultra Scope software allows RIGOL (RIGOL Technologies, Inc.)'s DS1000B Series oscilloscope through USB or RS-232 interface to connect PC, supported operating systems include: Windows 95, 98, 2000, NT, and Windows XP.
Ultra Scope software provides control and analysis functions are as follows:
through the data browser to display the captured waveform data and measured values
DSO controller through a local or remote operation of
in order to "BMP" bitmap format waveform
Waveform Record & Playback
the data is saved as "TXT" or "EXCEL" file in order to facilitate
