RIGOL DS1102CA Digital Oscilloscope/100MHz BW/2 Channel
Bandwidth |
100MHz |
Rise Time |
3.5ns |
Vertical Sensitivity |
2 mV/div to 10 V/div |
Real-time Sample Rate |
2 GSa/s(Single Channel), 1 GSa/s (DUal Channel) |
Equivalent Sample Rate |
50 GSa/s |
Scan Time Base |
5 ns/div to 50 s/div |
Display |
TFT (64K, Color LCD), 320 x 234 |
Channels |
2 |
Vertical Resolution |
8bit |
Input Max voltage |
300 V (DC + AC peak) |
Input Coupling |
DC, AC, Ground |
Trigger Modes |
Edge, Video, Pulse Width, Slope, Alternative |
Trigger Sources |
CH1,CH2,Ext,Ext/5,AC Line |
Automatic Measurements |
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Delay1-2, Delay 1-2 |
Cursor Measurements |
Manual, Track and Auto Measure modes |
I/O |
USB Device,USB Host,RS-232,P/F Out (Isolated) |
Sample Types |
Real Time, Equivalent Time |
Math |
Add, Subtract, Multiply, FFT, Invert |
Power Supply |
Worldwide Use, 100 – 240 V / 50 VA Max |
Size and Weight |
303mm×154mm×133mm, about2.3 kg |
Features:
*The 2 GSa/s maximum real-time sample rate,the 50 GSa/s maximum equivalent time
* sample rate and up to 300 MHz of bandwidth ensures you capture and observe your
* entire signal
* Up to 2000 wfms/s refresh rate
* Ultra Compact Design with small footprint save your bench space
*5.7 64K TFT color LCD, bright and vivid waveform display
* Memory depth: 10 kpts (Single Channel), 5 kpts (Dual Channels)
* Versatile trigger modes: Edge, Video, Pulse Width, Slope, Alternate
* Adjustable trigger sensitivity: Effectively filter noise from trigger signal and avoid false trigger
* 20 automatic measurements
* Cursor measurements: Manual, Track and Auto Measure modes
* 10 waveforms, 10 setups, BMP and CSV storage
* Math functions: Add, Subtract, Multiply, FFT, Invert
* Special digital filter and waveform recorder
* Built-in hardware frequency counters
* Dual channels plus external trigger. Bandwidth including 60 MHz, 100 MHz, 200 MHz, 300 MHz
* Standard interface: USB Device, RS-232;USB Host, to support USB disk and USB printer
* Standard configuration: Pass/Fail test,the signal out of the pass fail function is isolated to
* prevent unwanted interference
* Multi-language user interface, built-in help system
Standard accessories Include:
1x Power Cord (we will send the type you want, if not tell us, we will send your country type)
2x Probe
1x User Manual
