Home > Instruments & Meters > Meter for Electricity > Multimeter > General Digital Multimeters UNI-T UT58A Voltage Current Resistance Capacitance Temperature Meter Tester
General Digital Multimeters UNI-T UT58A Voltage Current Resistance Capacitance Temperature Meter Tester
US$ 1 - 20
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT58A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT216C 600A True RMS Digital Clamp Meters Auto Range W/Frequency Capacitance Temperature NCV TestUS$ 1 - 60MOQ: 5 Pieces -
UNI-T UT216A True RMS Digital Clamp Meters Auto Range w/ NCV Capacitance AC&DC Voltage AC Current Ohm Tester MultimetroUS$ 1 - 40MOQ: 5 Pieces
-
DY5500 Multi Function TesterUS$ 130 - 160MOQ: 1 Piece
-
Original TES PROVA 210 Solar Module Analyzer Prova-210US$ 950 - 1,200MOQ: 1 Piece
-
UTE1010A Uni-t Digital Power Meter True Rms Power Factor Analyzer 0.3W ~ 3000WUS$ 40 - 70MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT58A
Measuring Current Range
20μA/2mA/20mA/200mA/20A
Measuring Voltage Range
200mV-1000V
Measuring Resistance Range
200Ω/2kΩ/20kΩ/2MΩ/20MΩ/200MΩ
Measuring Capacitance Range
2nF/200nF/100μF
Operating Temperature
-40 °C - 1000°C
Dimensions
179mm*88mm*39mm
General Digital Multimeters UNI-T UT58A Voltage Current Resistance Capacitance Temperature Meter Tester
Introduction
UT58A digital multimeter manual range. It has a large screen, full-featured symbol display and input connections prompt, full scale overload protection and unique design, making it more superior performance of electrical instruments. Can be used to measure AC and DC voltage, DC current, resistance, temperature, frequency, diode forward voltage drop and circuit continuity, is ideal for the majority of users to carry maintenance tools.
Specification
| Specifications | Range | Best Accuracy | ||
| Model | UT58A | UT58B | UT58C | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.5%+1) | ±(0.5%+1) | ±(0.5%+1) |
| AC Voltage (V) | 2V/20V/200V/750V | ±(0.8%+3 | ±(0.8%+3 | ±(0.8%+3 |
| DC Current (A) | 20μA/2mA/20mA/200mA/20A | ±(0.8%+1) | ||
| 2mA/20mA/200mA/20A | ±(0.8%+1) | |||
| 2mA/200mA/20A | ±(0.8%+1) | |||
| AC Current (A) | 2mA/200mA/20A | ±(1%+3) | ±(1%+3) | ±(1%+3) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/2MΩ/20MΩ/200MΩ | ±(0.8%+1) | ±(0.8%+1) | |
| 200Ω/2kΩ/20kΩ/2MΩ/20MΩ | ±(0.8%+1) | |||
| Capacitance (F) | 2nF/200nF/100μF | ±(4%+3) | ±(4%+3) | ±(4%+3) |
| Frequency (Hz) | 2kHz/20kHz | ±(1.5%+5) | ||
| Temperature (°C) | -40 °C - 1000°C | ±(1%+3) | ±(1%+3) | |
| Features | ||||
| Display Count | 2000 | 2000 | 2000 | |
| Manual Range | √ | √ | √ | |
| Diode | √ | √ | √ | |
| Transistor | √ | √ | √ | |
| Auto Power Off | √ | √ | √ | |
| Continuity Buzzer | √ | √ | √ | |
| Data Hold | √ | √ | √ | |
| Low Battery Indication | √ | √ | √ | |
| Full Icon Display | √ | √ | √ | |
| Input Impedance for DCV | Around 10MΩ | √ | √ | √ |
| Test Lead Connection Indications | √ | √ | √ | |
| General Characteristic | ||||
| Power | 9V Battery96F22) (not included) | |||
| LCD Size | 60×54mm | |||
| Product Color | Red and Grey | |||
| Product Net Weight | 350g (Including holster) | |||
| Product Size | 179mm*88mm*39mm | |||
| Standard Accessories | UT58A-Battery, Test Lead,Holster,Muli-Purpose Socket | |||
| UT58B/UT58C-Battery, Test Lead,Holster,Muli-Purpose Socket,Point Contact Temperature Probe | ||||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 40 PCs | |||
| Standard Carton Measurement | 598*418*340mm (0.085 CBM Per Standard Carton) | |||
| Standard Carton Gross Weight | 27 Kg | |||
Accessory
1. Battery, (not included)
2. Test Lead,
3. Holster,
4. Muli-Purpose Socket,
