Place of Origin Guangdong, China
Brand Name UNI-T
Model Number UT216A
Display Type Digital Only
Measuring Current Range 6A/60A/600A ±(2.5%+5)
Measuring Voltage Range 6V/60V/600V/750V ±(1.2%+5)
Measuring Resistance Range 600ohm - 60Mohm ±(1%+2)
Measuring Capacitance Range 99.99nF - 59.99mF ±(4.0%+5)
Dimensions 220mm * 75mm * 40mm
Weight 453g / 1lb

UNI-T UT216A True RMS Digital Clamp Meters Auto Range w/ NCV Capacitance AC&DC Voltage AC Current Ohm Tester MultimetroUNI-T UT216A True RMS Digital Clamp Meters Auto Range w/ NCV Capacitance AC&DC Voltage AC Current Ohm Tester Multimetro







SPECIFICATIONS:

Display Count: 6000
Auto Range: √
Jaw Capacity: 30mm
True RMS: √
Diode: Around 3.0V
NCV: √
Data Hold: √
Relative Mode: √
MAX/MIN: √
LCD Backlight: √
Flashlight: √
Auto Power Off: Around 15 Minutes
Continuity Buzzer: √
Low Battery Indication: ≤3.6V
Input Protection: √
Input Impedance for DCV: ≥10M?


Model: UT216A
AC Current (A): 6A/60A/600A ±(2.5%+5)
AC Voltage (V): 6V/60V/600V/750V ±(1.2%+5)
DC Voltage (V): 600mV/6V/60V/600V/1000V ±(0.8%+1)
Resistance (?): 600?/6K?/60K?/600K?/6M?/60M? ±(1%+2)
Capacitance: 99.99nF/999.9nF/9.999?F/99.99?F/999.9?F/9.999mF/59.99mF ±(4.0%+5)

General Characteristic:
Power: AAA 1.5V * 3 (not included)
Product Net Weight: 231.7g
Product Size: 220mm * 75mm * 40mm
LCD Size: 38mm * 24 mm
Product Color: Red and Grey
Package Size: 23.5 * 9 * 6cm / 9.3 * 3.5 * 2.4in
Package Weight: 453g / 1lb



Package:

100% Brand new

1 * UNI-T UT216A Digital Clamp Meter
1 * Test Lead
1 * Carrying Bag
1 * English Manual
