UTE1010A Uni-t Digital Power Meter True Rms Power Factor Analyzer 0.3W ~ 3000W
US$ 40 - 70
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UTE1010A
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UNI-T UT70B LCD Digital Multimeter Frequency Conductance Logic Test Transistor Temperature Analog DisplayUS$ 55 - 75MOQ: 1 Piece -
Uni T Ut512 Insulation Resistance Tester Meter Ohm 2500v Usb Interface OhmUS$ 80 - 110MOQ: 1 Piece
-
2500V Digital Insulation Resistance Meter Tester Megohmmeter Highly Voltmeter Continuity Tester W/LCD Backlight UNI-T UT502AUS$ 50 - 75MOQ: 1 Piece
-
UNI-T UT70C LCD Digital Multi-purpose Meter Multimeters Volt Amp Ohm Capacitance Tester UT-70CUS$ 70 - 90MOQ: 1 Piece
-
Multifunctions Insulation Resistance Testers UNI-T UT529A Digital Earth Tester 125V/250V/500V Voltage Frequency TesterUS$ 150 - 210MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UTE1010A
Measuring Current Range
2m A~10A
Measuring Voltage Range
1.0V~300V
Dimensions
220mm*100mm*305mm
UTE1010A Uni-t Digital Power Meter true rms Power Factor Analyzer 0.3W ~ 3000W
Features
• Digital display for easy reading;
• Four windows simultaneously display True RMS voltage, RMS current, peak current, power, power factor, frequency, test quickly;
• Voltage and current range automatic conversion, improve the measurement accuracy;
• Waveform measurement accuracy is not affected;
• High reliability, long life;
• Free to set upper and lower parameters, qualified information ring power. Batch testing to improve efficiency.
Technical Parameters
| Specification | Range | |||
| Model | UTE1003A | UTE1010A | UTE1003B | UTE1010B |
| Display | 4 Displays; V, A, Apk,W, PF,F | |||
| Voltage | 1.0V~300V | 1.0V~300V | 1.0V~300V | 1.0V~300V |
| Current | 2m A~3A | 2m A~10A | 0.2m A~3A | 0.2m A~10A |
| Power Range | 0.01W ~ 900W | 0.3W ~ 3000W | 0.001W ~ 900W | 0.01W ~ 3000W |
| Range Switch | Auto | |||
| PF | -1.000~+1.000 | |||
| Accuracy | 0.4%reading+0.1%range+1digit | |||
| Frequency Range | 15Hz ~ 650Hz ,Bandwidth:5kHz | |||
| Over-limit Judgment | OK | |||
| Inerface | RS-232 | -- | RS-232 | RS-232 |
| General Characteristics | ||||
| Power | Input Voltage:115VAC / 230VAC;Frequency:47Hz~63Hz | |||
| Product Colour | White and Gray | |||
| Product Net Weight | 2.6 Kg | 2.3 Kg | 2.6 Kg | 2.6 Kg |
| Product Size (W×H×D) | 220mm×100mm×365mm | 220mm×100mm×305mm | 220mm×100mm×365mm | |
| Standard Accessories | Power Cord | |||
| Standard Individual Packing | Gift Box, English Manual | |||
| Standard Quantity Per Carton | 1 PCs | |||
| Standard Carton Measurement (L×W×H) | 480mm×310mm×200mm ( 0.029CBM Per Export Carton) |
420mm×310mm×200mm ( 0.026CBM Per Export Carton) |
480mm × 310 mm ×200 mm (0.029CBM Per Export Carton) |
|
| Standard Carton Gross Weight | 3.4 Kg | 3.1 Kg | 3.4 Kg | 3.4 Kg |
| Optional Accessories | ||||
| RS232 (UTE1010A) | ||||
Packing including:
Power Cord.
