Home > Instruments & Meters > Meter for Electricity > Multimeter > KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V

KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V

KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V thumbnail-1
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V thumbnail-2
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V thumbnail-3
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V thumbnail-4
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V photo-1
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V photo-2
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V photo-3
KYORITSU 1110 Analogue Multimeter High Sensitivity DC20kohm/V photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
1110
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name KYORITSU
Model Number 1110
Measuring Current Range 300mA
Measuring Voltage Range 600V
Measuring Resistance Range 300KΩ
Dimensions 140(L) * 94(W) * 39(D) mm

 KYORITSU 1110 Analogue Multimeter High sensitivity DC20kohm/V



KYORITSU 1110 Analogue Multimeter High sensitivity DC20kohm/V







• High sensitivity DC20kΩ/V.
• 1m drop-proof heavy duty designed taut-band movement.
• Can measure line voltage up to AC 600V.
 (Voltage to ground MAX AC300V)
 (Protected by 600V ceramic fuse against accidental overload)
• Continuity buzzer, battery check, LED check, temperature
 measurement function.
• Skeleton type robust and clear case
 with carrying handle furnished as standard accessory.


DC V 0.3V (16.7kΩ/V) ±3% of FS
3/12/30/120/300/600V (20kΩ/V)
±3% of FS
AC V 12V (9kΩ/V) ±4% of FS
30/120/300/600V (9kΩ/V)
±3% of FS
DC A 60µA/30/300mA
±3% of FS
Ω 3/30/300kΩ
±3% of scale length
Continuity buzzer Buzzer sounds below 100Ω
Battery Test 1.5V (0.7 - 2V)
±3% of FS (10Ω load)
Temperature -20ºC - +150ºC
±3% of scale length (0ºC - +100ºC)
±4% of scale length (other ranges)
(with the use of Temperature probe 7060)
LED 10mA approx. at 0 Ω
(at 3V of battery voltage)
Applicable standards IEC 61010-1
 CAT III 300V Pollution Degree 2
 CAT II 600V Pollution Degree 2
IEC 61010-2-031
Power source R6 (AA) (1.5V) × 2
Dimensions 140(L) × 94(W) × 39(D) mm
Weight 280g approx.
Included Accessories 7066A (Test leads)
8923 (F500mA/600V fuse) × 2
R6 (AA) × 2
9103 (Carrying case)
Instruction Manual
Optional Accessories 7060 (Temperature probe)
