KYORITSU 2002PA AC Digital Clamp Meters up to 2000A Peak Hold

Name: KYORITSU 2002PA AC Digital Clamp Meters up to 2000A Peak Hold
Brand: KYORITSU
SKU: 130758609
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Japan

Brand Name:

KYORITSU

Model Number:

2002PA

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ShenZhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Japan

Brand Name KYORITSU

Model Number 2002PA

Display Type Digital Only

Measuring Current Range 400A

Measuring Voltage Range 1000V

Measuring Resistance Range 400kΩ

Dimensions 247(L) * 105(W) * 49(D)mm

Weight 470g

KYORITSU 2002PA AC Digital Clamp Meters up to 2000A Peak Hold

• Can measure large AC current up to 2000A.
• Peak hold function.
• 55mm-dia large tear drop shaped jaws.

AC A	400A (0 - 400A) ±1%rdg±3dgt [50/60Hz] ±2%rdg±3dgt [40Hz - 1kHz] 2000A (0 - 1500A) ±1%rdg±3dgt [50/60Hz] ±3%rdg±3dgt [40Hz - 1kHz] 2000A (1500 - 2000A) ±3.0%rdg [50/60Hz]
AC V	40/400/750V ±1%rdg±2dgt [50/60Hz] ±1.5%rdg±3dgt [40Hz - 1kHz]
DC V	40/400/1000V ±1%rdg±2dgt
Ω	400Ω/4k/40k/400kΩ ±1.5%rdg±2dgt
Continuity buzzer	buzzer sounds below 50±35Ω
Conductor size	Ø55mm max.
Frequency response	40Hz - 1kHz
Output	Recorder : DC400mV against AC400A DC200mV against AC2000A
Safety Standard	IEC 61010-1 CAT III 600V , CAT II 1000V IEC 61010-2-031 IEC 61010-2-032
Power source	R6 (AA) (1.5V) × 2
Dimensions	247(L) × 105(W) × 49(D)mm
Weight	470g approx.
Included Accessories	7107A (Test leads) 8201 (Output Plug) 9094 (Carrying Case) R6 (AA) × 2 Instruction Manual
Optional Accessories	8008 (Multi-Tran) 7256 (Output cord)
