KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter

KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter thumbnail-1
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter thumbnail-2
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter thumbnail-3
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter thumbnail-4
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter photo-1
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter photo-2
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter photo-3
KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Japan
Brand Name:
KYORITSU
Model Number:
2300R
Contact Supplier Request Quote Chat Now
Shenzhen Graigar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Japan
Brand Name KYORITSU
Model Number 2300R
Display Type Digital Only
Measuring Current Range 100A
Dimensions 161.3(L) * 40.2(W) * 30.3(D)mm
Weight 110g



KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter



KYORITSU 2300R 100A True RMS Non Contact Fork Current Tester Meter







When load current is not affected by the distortion, both averaging value type and true RMS (root mean square) type clamp meters show the almost same value of about 10A with constant wave-form as the above display samples. However, when load current is affected by some distortions such as inverter, etc...,averaging value type clamp meter indicates 5.5A instead of 9.7A and true RMS type clamp meter indicates 7.9A instead of 9.7A with irregular wave-form. Accordingly, true RMS type clamp meter is recommendable for the measurement of the equipment with inverter control devices.
Due to the use of thyristors, inverters and other energy-saving controllers in recent electric wiring, current waveforms often include harmonic components and are distorted compared to sinusoidal waves (50/60Hz).
 The Kyoritsu True RMS value tester is able to measure distorted waveforms using true RMS since waveforms are being internally calculated continuously. In contrast, when measurements are made with a averaging value tester, errors are generated in the measurement value because the tester cannot continuously track distorted waveforms.

(Compared to the true RMS value tester, measurement values for the averaging value generate more than 30% errors in some cases.)



Current measurement AC A 0 to 100.0A ±2.0%rdg±5dgt (50/60Hz)
DC A 0 to ±100.0A ±2.0%rdg±5dgt
Crest factor 2.5
Non contact voltage Detect AC voltage without contacting with socket wire
During voltage detection, "Hi" flashes and a buzzer sounds
Maximum digit 1,049
Conductor size Max Ø10mm
Safety Standard IEC 61010-1 CAT III 300V Pollution degree 2
Power source R03 (AAA) × 2 (Auto power off: approx.10 minutes)
*Continuous measuring time: AC A approx. 46 hours DC A approx. 52 hours
Dimensions 161.3(L) × 40.2(W) × 30.3(D)mm
Weight 110g (with batteries)
Included Accessories 9113 (Carrying Case)
R03 (AAA) × 2
Instruction Manual
