Home > Products > Corrugated Carton Machinery > CMYK 1224 High speed carton printing machine
CMYK 1224 High speed carton printing machine
- 10 Set / Sets per Month
- Any port of China
- T/T L/C D/P D/A
Product Details
Condition: | New | Plate Type: | Letterpress | Place of Origin: | Shanghai, China |
Brand Name: | SPIC carton printing machine | Model Number: | 2400 carton printing machine | Usage: | Other, carton printing machine, carton printing machine |
Automatic Grade: | Automatic | Voltage: | 380V 50Hz | Gross Power: | 30KW |
Dimensions(L*W*H): | 4x1.8x12 | Weight: | 10T | Certification: | CE |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High Speed Carton Printing Machine
Features:
The machine is designed and made for high quality, high speed, high efficiency, high stability and high safety, convenient for quick order update and operation.
Made with high quality materials and parts.
Well hardened and ground transmission gears.
Auto zero return and auto reset.
All gaps between cylinders and rollers are manual adjustment, with auto-lock device.
All cylinders and rollers are hard chromed for ideal hardness.
Controlled by motor
All electric, electronic and pneumatic components are of European standards.
Parameters:
Data & Model | 900×2000 | 1200×2000 | 1200×2400 | 1400×2400 | 1600×2800 | |
Max. mechanic speed(pcs/min) | 200 | 200 | 200 | 200 | 180 | |
Max. feeding size(mm) | 880×2000 | 1180×2000 | 1180×2000 | 1380×2400 | 1600×2800 | |
Min. feeding size(mm) | 280×650 | 320×750 | 320×750 | 360×750 | 420×750 | |
Skip feeding(mm) | 1100×2000 | 1500×2000 | 1500×2400 | 1700x2400 | 1900×2800 | |
Max. printing area(mm) | 800×2000 | 1150×2000 | 1150×2400 | 1320x2400 | 1540×2800 | |
Max. thickness of board(mm) | 7.2 | 7.2 | 7.2 | 7.2 | 7.2 | |
Min. slotting size | Slotting type L.(mm) | 160×160×160×160 | 160×160×160×160 | 160×160×160×160 | 160×160×160×160 | 165×165×165×165 |
Slotting type L.(mm) | 240×80×240×80 | 250×90×250×90 | 250×90×250×90 | 280×90×280×90 | 260×90×260×90 | |
Max. slot depth(mm) | 250 | 320 | 320 | 320 | 560 | |
Max. thickness of board(mm) | 12 | 12 | 12 | 12 | 12 | |
Dimension(L×W×H)(mm) Note:S-Single D-Double T-Three F-Four | 11659×4240×3200 | 13015×4400×3500 | 13015×4800×3500 | 13570×4820×3500 | 14021×5220×3500 | |
12079×4240×3200 | 13550×4400×3500 | 13550×4800×3500 | 14208×4820×3500 | 14701×5220×3500 | ||
|
|
|
|
Note: Machinde sizes can be customzied according to customers.
Feeding Unit:
v Lead feed system with four-shaft structure is controlled by servo.
v Vacuum suction system. The air volume can be set in accordance with different paperboard bending conditions so as to feed paper smoothly.
v Double feeding roller device can ensure the best stabilization in feeding.
v Speed Motor Control Feeder (Optional inverter control)
v The main motor activates the protection device. If the unit is not locked, the main motor can not start.
v The clearance of feeding roller is regulated by hand and the scope is 0-11mm.
v Automatic zero setting and reset.
Printing Unit:
v Quick hanging form device can save more time. And 360 degree adjustment. And automatic reset.
v A switch regulated by feet makes the roller turn clockwise and anticlockwise. So it is convenient to load and unload the form.
v Steel anilox roller,(Optional equipment— ceramic anilox roller)
v Anilox roller and rubber roller is adjusted by pneumatic control system.
v Regulating printing phase position is motorized by planetary gear system and text display.
Slotting Unit
v Height of the carton is adjusted by motor, and ruler displays.
v The slotting clearance and the creasing clearance is adjusted synchronously by motor.
v Phase position is regulated by motorized planetary gear.
v Pre-creasing tool covered with YOU LI rubber to prevent crushing board.
* The above information and specifications are subjects to change without prior notification.
* SPIC reserves all the rights for final explanations.
Shanghai Printpack dedicate to provide "value+" service to those who in need of quality and resonable priced equipment for printing and packaging industry.
Our team of seasoned professional consultants are willing to offer range of products in print & pack machinery of hi performanced, as well as optimizing supply chain management for overseas customer sourcing from China.
We are willing to play as an important partner for those who got inspired by China's growth.
